(140SR-3) - ACERA CRAWLER EXCAVATOR - ASN YH07-09001 (6/12-12/13)
/
VALVE YX30V00006F3

VALVE YX30V00006F3

VALVE YX30V00006F3

1 YX30V00006F3

  • YX30V00006F3 - VALVE
  • Control Flow
  • Incl 2 - 10

2 2441U722S490

  • 2441U722S490 - PLUG

3 ZS23C08060

  • ZS23C08060 - SCREW
  • Hex Socket Head
  • M8 x 60mm
  • Cap

4 YN20V00004S400

  • YN20V00004S400 - VALVE
  • ASSY.

5 ZD12P02000

  • ZD12P02000 - O-RING
  • 2.4mm Thk x 19.8mm ID
  • 90 Duro

6 ZD85P02000

  • ZD85P02000 - RING
  • Back-Up

7 YB15V00003S390

  • YB15V00003S390 - PLATE

8 2437U407S983

  • 2437U407S983 - RIVET

9 LQ15V00001S984

  • LQ15V00001S984 - PLUG

10 YZ10V00002S732

  • YZ10V00002S732 - O-RING
