VALVE YN25V00004P1
1 YN25V00004P1
- YN25V00004P1 - VALVE
- Stop
2 YY21P01029P1
- YY21P01029P1 - HOSE ASSY.
3 HX11F06032DX
- HX11F06032DX - FLEXIBLE HOSE
- 9.70mm ID x 320mm L
4 HX11F06170DX
- HX11F06170DX - HOSE ASSY.
- 9.70mm ID x 1700mm L
5 HX11F06200DX
- HX11F06200DX - HOSE ASSY.
- 9.70mm ID x 2000mm L
6 HX11F06300DX
- HX11F06300DX - HOSE ASSY.
- 9.70mm ID x 3000mm L
7 HX11Y05032DY
- HX11Y05032DY - HOSE
8 HX11Y05066DY
- HX11Y05066DY - HOSE
9 HX81X19022DX
- HX81X19022DX - TUBE
10 HX81X19160DX
- HX81X19160DX - FLEXIBLE HOSE
11 HX81X19185DX
- HX81X19185DX - TUBE
12 HX81X19210DX
- HX81X19210DX - TUBE
13 HX81X19290DX
- HX81X19290DX - TUBE
14 PH05P01088D7
- PH05P01088D7 - CLIP
- 13.6mm - 17.5mm
15 PY01P01043D2
- PY01P01043D2 - CABLE TIE
- 4.60mm W x 202mm L
16 YN13E01375P1
- YN13E01375P1 - CLIP
- M8 x 8.20mm Shank
17 ZC46X16011
- ZC46X16011 - CLIP
18 ZC46X25011
- ZC46X25011 - CLIP
19 ZC48X24014
- ZC48X24014 - CLIP
20 ZM73C10016
- ZM73C10016 - BOLT
- M10x16mm - Course Thread
- Sems
21 ZM73C10035
- ZM73C10035 - BOLT
- M10x35mm - Course Thread
- Sems
22 VA32K6200010
- VA32K6200010 - FILTER ASSY
- Assy
- Pre
- See Fig 88.100.41
23 ZS18C10025
- ZS18C10025 - SCREW
- Hex
- M10 x 25mm
- Cap
24 VA32K6200020
- VA32K6200020 - FUEL FILTER
- Assy
- Main
- See Fig 88.100.41
25 ZW16P10000
- ZW16P10000 - WASHER
