(SK235SR-1E) - SHORT RADIUS EXCAVATOR ASN YF04-01501 (1/03-12/04)
/
SEAT BELT,48mm W x 1250mm L, Black

SEAT BELT,48mm W x 1250mm L, Black

SEAT BELT,48mm W x 1250mm L, Black

1 PW25M00015F1

  • PW25M00015F1 - SEAT BELT
  • 48mm W x 1250mm L
  • Black

2 ZM73C10025

  • ZM73C10025 - BOLT
  • M10x25mm - Course Thread
