(SK235SR-1E) - SHORT RADIUS EXCAVATOR ASN YF04-01501 (1/03-12/04)
/
SHOE ASSY - H&D, 800 mm (31 in)

SHOE ASSY - H&D, 800 mm (31 in)

SHOE ASSY - H&D, 800 mm (31 in)

1 LQ60D00019F1

  • LQ60D00019F1 - SHOE ASSY - H&D
  • 800 mm (31 in)

2 LQ60D00019F2

  • LQ60D00019F2 - SHOE ASSY - H&D
  • 900 mm (35 in)

3 LQ60D00019F3

  • LQ60D00019F3 - SHOE ASSY - H.D.
  • H&W
  • 700 mm (28 in)

4 24100J12423F1

  • 24100J12423F1 - CHAIN LINK

5 2424N231

  • 2424N231 - TRACK LINK

6 2424N232

  • 2424N232 - TRACK LINK

7 2419P4213

  • 2419P4213 - PIN
  • 41.84mm OD x 230mm L

8 2405P425C3

  • 2405P425C3 - BUSHING

9 2419P4212

  • 2419P4212 - PIN
  • 42mm OD x 230mm L

10 2405P426C3

  • 2405P426C3 - BUSHING

11 2418T21591

  • 2418T21591 - COLLAR

12 2445Z1506

  • 2445Z1506 - SEAL

13 2420T7458

  • 2420T7458 - BOLT
  • Spher Hex
  • M20 x 1.5 x 60mm
  • Cl 2

14 LQ60DU1001P1

  • LQ60DU1001P1 - BOLT
  • Spher Hex
  • M20 x 1.5 x 64.50mm

15 2420P1552

  • 2420P1552 - NUT
  • M20
  • 1.5mm Pitch
  • HT

16 2415N366

  • 2415N366 - SHOE

17 2424N263

  • 2424N263 - TRACK SHOE

18 LQ60DU0010P1

  • LQ60DU0010P1 - SHOE
