WIRE HARNESS 85805380

WIRE HARNESS 85805380

WIRE HARNESS 85805380

1 85805380

  • 85805380 - WIRE HARNESS

2 85806137

  • 85806137 - WIRE HARNESS

3 85806133

  • 85806133 - FLASHER SWITCH

4 14143790

  • 14143790 - BULB
  • 12V
  • 1.2W

5 83961521

  • 83961521 - LIGHT SWITCH

6 13309417

  • 13309417 - SCREW
  • Pozidriv Oval Hd
  • Csk
  • M4 x 20mm
  • Cl 5.8
  • Full Thd

7 89824840

  • 89824840 - WASHER
  • 4.3mm ID x 9mm OD x 0.8mm Thk

8 81865261

  • 81865261 - WASHER
  • 6.8mm ID x 12mm OD x 3mm Thk
