(B110B) - BACKHOE LOADER - TIER 3 (11/10-)
/
PLATE 84150368

PLATE 84150368

PLATE 84150368

1 84150368

  • 84150368 - PLATE

2 87378121

  • 87378121 - PIN
  • 30mm OD x 84mm L

3 12647121

  • 12647121 - WASHER
  • 8.15mm ID x 20mm OD x 3mm Thk

4 84150407

  • 84150407 - PLATE

5 86511325

  • 86511325 - WASHER
  • 15mm ID x 28mm OD x 2.5mm Thk

6 412370

  • 412370 - NUT
  • M14 x 2
  • Cl 8

7 11067871

  • 11067871 - SNAP RING
  • M30
  • Ext

8 84314326

  • 84314326 - SLIDING PAD

9 11094921

  • 11094921 - BOLT
  • Hex
  • M14 x 210mm
  • Cl 8.8

10 84322680

  • 84322680 - SHIM
  • 225mm L x 40mm W x 1mm Thk

11 43127

  • 43127 - BOLT
  • Hex
  • M8 x 1.25 x 25mm
  • Cl 8.8
