(B110B) - BACKHOE LOADER TIER 3 (2008)
/
STEERING KNUCKLE,3 Holes (King Pin Fixing), 8 Holes (Hub Side), 60mm ID (Seal Ring Seat) 85827740 (3)

STEERING KNUCKLE,3 Holes (King Pin Fixing), 8 Holes (Hub Side), 60mm ID (Seal Ring Seat) 85827740 (3)

STEERING KNUCKLE,3 Holes (King Pin Fixing), 8 Holes (Hub Side), 60mm ID (Seal Ring Seat) 85827740 (3)

1 85827740

  • 85827740 - STEERING KNUCKLE
  • 3 Holes (King Pin Fixing)
  • 8 Holes (Hub Side)
  • 60mm ID (Seal Ring Seat)

2 85827739

  • 85827739 - STEERING KNUCKLE
  • 3 Holes (King Pin Fixing)
  • 8 Holes (Hub Side)
  • 60mm ID (Seal Ring Seat)

3 85805987

  • 85805987 - SCREW
  • M16 x 100mm

4 85805989

  • 85805989 - CYLINDER HEAD

5 87306927

  • 87306927 - STEERING TIE-ROD

6 85805976

  • 85805976 - NUT
  • M18 x 1.5

7 85805975

  • 85805975 - BALL JOINT
  • M18 / M20

8 85805988

  • 85805988 - BRONZE BUSHING
  • 45.08mm ID x 50.12mm OD x 35mm L

9 85824345

  • 85824345 - OIL SEAL
  • 45mm ID x 60mm OD x 16mm Thk

10 9968021

  • 9968021 - LUBE NIPPLE
  • M6 x 1 x 16mm OAL

11 9968022

  • 9968022 - SCREW
  • M14 x 2 x 35mm

12 9968023

  • 9968023 - PIVOT

13 85805986

  • 85805986 - NUT
  • M16

14 9968025

  • 9968025 - PIVOT

15 85805982

  • 85805982 - NUT
  • M18 x 1.5

16 85805978

  • 85805978 - STEERING CYLINDER

17 85805978R

  • 85805978R - REMAN-HYD CYLINDER

18 85805978C

  • 85805978C - CORE-HYD CYLINDER

19 9968028

  • 9968028 - SCREW

20 85805990

  • 85805990 - OIL SEAL

21 85805992

  • 85805992 - ROD

22 85805984

  • 85805984 - LUBE NIPPLE

23 87306934

  • 87306934 - TIE-ROD
