(B110B) - BACKHOE LOADER TIER 3 (2008)
/
TEMPERATURE SENDER 47048895 (3)

TEMPERATURE SENDER 47048895 (3)

TEMPERATURE SENDER 47048895 (3)

1 47048895

  • 47048895 - TEMPERATURE SENDER

2 16104111

  • 16104111 - NUT
  • Prevailing Torque
  • M8
  • 1.25 Pitch
  • 10.6mm High
  • Cl 08
  • ZND

3 12647121

  • 12647121 - WASHER
  • 8.15mm ID x 20mm OD x 3mm Thk

4 85820156

  • 85820156 - ADAPTER
  • 1/8" - 28 x 9/16" - 18 ORB

5 85817672

  • 85817672 - PRESSURE SWITCH

6 11197879

  • 11197879 - BELLEVILLE WASHER
  • 8.4mm ID x 16mm OD x 2.2mm Thk

7 87409316

  • 87409316 - SWITCH

8 87613641

  • 87613641 - SUPPORT

9 47048993

  • 47048993 - LOCK WASHER
  • 10mm ID

10 47049010

  • 47049010 - BOLT
  • Hvy Hex
  • M10 x 20mm
  • Cl 8.8

11 47049031

  • 47049031 - NUT
  • M10 x 1.5
  • Cl 10

12 87407206

  • 87407206 - GROUND STRAP

13 16043421

  • 16043421 - BOLT
  • Hex
  • M8 x 1.25 x 20mm
  • Cl 8.8
  • Full Thd

14 85826964

  • 85826964 - HYD CONNECTOR

15 87427925

  • 87427925 - CABLE
  • 1760mm L

16 87636291

  • 87636291 - CABLE
  • 450mm L

17 87492241

  • 87492241 - FITTING
