New Holland Construction
/
(B95C) - BACKHOE LOADER - TIER 4B (2/15-)
/
VALVE, CHECK 87426716 (2)

VALVE, CHECK 87426716 (2)

VALVE, CHECK 87426716 (2)

1 87426716

  • 87426716 - VALVE
  • CHECK

2 NSS

  • NSS - NOT SOLD SEPARAT

3 87455974

  • 87455974 - O-RING
  • 0.097" Thk x 0.755" ID

4 87308524

  • 87308524 - HOUSING

5 NSS

  • NSS - NOT SOLD SEPARAT

6 87309001

  • 87309001 - O-RING

7 87308528

  • 87308528 - PLUG

8 87446003

  • 87446003 - SPRING
  • 6.7mm OD

9 87446002

  • 87446002 - POPPET
