Электрика рамы
1 803598981
- 803598981 - Work light
2 801968716
- 801968716 - With rubber strip clamp small 15
3 125811695
- 125811695 - Rear light bracket
4 805049471
- 805049471 - Bolt M6X20
- Кол-во: GB/T16674.1-2004
5 801900028
- 801900028 - Cable tie 4.8X200
6 803688302
- 803688302 - Line bracket
7 805004518
- 805004518 - Bolt M6X20
- Кол-во: GB/T16674.1-2004
8 803684273
- 803684273 - Two-way cable tie
9 801973330
- 801973330 - With rubber strip clamp ①35
10 125813204
- 125813204 - Wiring harness from control box to control room
11 125813420
- 125813420 - Wiring harness fixing bracket
12 125811111
- 125811111 - Lighting system
13 125813093
- 125813093 - Control box assembly
14 125813899
- 125813899 - Battery box installation
15 803587307
- 803587307 - Electric horn
16 801905273
- 801905273 - With rubber strip clamp small 30
17 801905408
- 801905408 - With rubber strip clamp
18 125813094
- 125813094 - Girder wiring harness
19 803609935
- 803609935 - speaker
20 805047870
- 805047870 - Bolt M8X12
- Кол-во: GB/T16674.1-2004
21 805046481
- 805046481 - Bolt M6X16 (Dacro)
- Кол-во: GB/T5783-2000
22 125811705
- 125811705 - Speaker cover
23 125811693
- 125811693 - Rear light bracket
24 125813160
- 125813160 - Wiring harness from control box to lifting arm
25 805140015
- 805140015 - Screw M5X16 (Dacro)
- Кол-во: GB/T818-2000
26 805338380
- 805338380 - Washer 5 (Dacro)
- Кол-во: GB/T93-1987
27 805338383
- 805338383 - Washer 5 (Dacro)
- Кол-во: GB/T97.1-2002
