Электрика стрелы
1 803684274
- 803684274 - Two-way cable tie
2 805338382
- 805338382 - Washer 4 (Dacro)
- Кол-во: GB/T97.1-2002
3 805140011
- 805140011 - Screw N4X16 (Dacro)
- Кол-во: GB/T818-2000
4 805338379
- 805338379 - Washer 4 (Dacro)
- Кол-во: GB/T93-1987
5 801905273
- 801905273 - With rubber strip clamp small 30
6 805047870
- 805047870 - Bolt N8X12
- Кол-во: GB/T16674.1-2004
7 801905272
- 801905272 - With rubber strip clamp small 18
8 803107979
- 803107979 - Pipe clamp
9 125811108
- 125811108 - Electrical wiring diagram of lifting arm
10 819900135
- 819900135 - Collar
11 125812453
- 125812453 - Line pressure plate
12 801905297
- 801905297 - With rubber strip clamp small 8
13 803598981
- 803598981 - Work light
14 801900028
- 801900028 - Cable tie 4.8X200
15 803688302
- 803688302 - Line bracket
16 125811114
- 125811114 - Lifting arm harness
17 803597120
- 803597120 - LED warning light (magnetic)
18 803590783
- 803590783 - Length angle sensor (〔⑷⑷-right position
19 805004760
- 805004760 - Bolt N8X30 (Dacro)
- Кол-во: GB/T16674.1-2004
20 805203166
- 805203166 - Nut N8
- Кол-во: GB/T6177.1-2000
21 801300088
- 801300088 - Rope clamp 6KTH
22 803700108
- 803700108 - Shackle T-DW0.63
23 125812463
- 125812463 - Mounting plate
24 805004518
- 805004518 - Bolt N6X20
- Кол-во: GB/T16674.1-2004
25 801968716
- 801968716 - With rubber strip clamp small 15
