Система охлаждения аккумулятора
1 125814686
- 125814686 - Water pipe
2 125814674
- 125814674 - Water pipe
3 125814680
- 125814680 - Water pipe
4 800368469
- 800368469 - Plug in and take over
5 125813270
- 125813270 - The inner diameter of the water pipe is smallф25-135
6 125813247
- 125813247 - The inner diameter of the water pipe is smallф25-280
7 801900096
- 801900096 - Clamp No: 0x332-ф44
- Кол-во: JB/T8870-1999
8 125814676
- 125814676 - Water pipe
9 805004520
- 805004520 - Bolt M8X15
- Кол-во: GB/T16674.1-2004
10 801900062
- 801900062 - Clamp No: 0x119-ф29
- Кол-во: JB/T8870-1999
11 125814682
- 125814682 - Water pipe
12 801973330
- 801973330 - With rubber strip clampф35
13 125814677
- 125814677 - Water pipe
14 125814679
- 125814679 - Water pipe
15 125814678
- 125814678 - Water pipe
16 125814685
- 125814685 - Water pipe
17 127001873
- 127001873 - Three-way connector
18 127001818
- 127001818 - Three-way connector II
19 800369083
- 800369083 - Battery radiator 1
20 125814673
- 125814673 - Water pipe
21 125814671
- 125814671 - Water pipe
22 805201542
- 805201542 - Nut M10
- Кол-во: GB/T6187.1-2000
23 125814687
- 125814687 - Water pipe
24 127001831
- 127001831 - Upholstery
25 805004537
- 805004537 - Bolt M10X40
- Кол-во: GB/T16674.1-2004
26 125813263
- 125813263 - The inner diameter of the water pipe is smallф25-1065
27 125814668
- 125814668 - Water pipe
28 125814669
- 125814669 - Water pipe
29 125814672
- 125814672 - Water pipe
30 125813305
- 125813305 - Water pipe 1
31 125814670
- 125814670 - Water pipe
32 127001819
- 127001819 - The inner diameter of the water pipe is smallф16-105 (wall thickness 5mm)
33 125813244
- 125813244 - Transition takeover
34 125814683
- 125814683 - Water pipe
35 127001869
- 127001869 - Steel pipe
36 125814681
- 125814681 - Water pipe
37 800369084
- 800369084 - Battery radiator 2
38 125814684
- 125814684 - Water pipe
39 125814675
- 125814675 - Water pipe
40 125814667
- 125814667 - Water pipe
41 125814666
- 125814666 - Water pipe
42 800167556
- 800167556 - Expansion tank
43 125811556
- 125811556 - bracket
