CYLINDER, ARM 7156578 (3)
1 7156578
- 7156578 - CYLINDER
- ARM
- Ref. 3-18 - Also Order (2) of 6652915 dust seal - Was 7148322
2 6586570
- 6586570 - HEAD
- 2.0" tall
3 6814983
- 6814983 - HEAD
- 2.25" tall
4 7147317
- 7147317 - PISTON
- Was 6810022
5 6810540
- 6810540 - NUT
6 6817317
- 6817317 - HOUSING
- .9" of threads - 3.5" (88
- 9 mm) OD - 3.26" (82
- 8 mm) ID
7 6816855
- 6816855 - PLUG
- W/Ref. 8
8 75K6
- 75K6 - O-RING
9 6686999
- 6686999 - WIPER
- ROD CYL
10 6667327
- 6667327 - SEAL
- ROD
11 82K236
- 82K236 - O-RING
12 73K234
- 73K234 - RING
- BACK-UP
- back-up - Was 80K234
13 54K40300
- 54K40300 - O-RING
- Was 58K234
14 6513466
- 6513466 - PISTON RG
15 54K30226
- 54K30226 - O-RING
- Was 25K30226
16 6803863
- 6803863 - BUSHING
17 7148323
- 7148323 - ROD
- Also Order Ref. 16 & (2) of 6652915 dust seal
18 7000771
- 7000771 - RING
- WEAR
- Was 6698133
19 7162060
- 7162060 - KIT
- SEAL
- Ref. 5
- 9-15 & 18 - Was 7156581
