Bobcat
/
435.0
/
PORT PLATE 6690064 (1)

PORT PLATE 6690064 (1)

PORT PLATE 6690064 (1)

1 6690064

  • 6690064 - PORT PLATE
  • Ref. 3
  • 24-48 & 50

2 6691612

  • 6691612 - ROTARY GROUP

3 6690061

  • 6690061 - ROTARY GROUP

4 6686301

  • 6686301 - STOP
  • cradle - Was 6686617

5 6686607

  • 6686607 - SPRING

6 6686300

  • 6686300 - ASSY
  • PISTON

7 6686307

  • 6686307 - SPRING
  • pressure

8 6686936

  • 6686936 - GASKET

9 6686916

  • 6686916 - SPINDLE

10 6686302

  • 6686302 - SWIVEL
  • BALL JOINT

11 6686626

  • 6686626 - CLIP

12 6691608

  • 6691608 - RETAINER

13 6691616

  • 6691616 - SCREW

14 6686313

  • 6686313 - SEAL
  • RING

15 6686311

  • 6686311 - BEARING

16 6691607

  • 6691607 - SHAFT

17 6691617

  • 6691617 - PLATE
  • swash

18 6686937

  • 6686937 - O-RING

19 6691611

  • 6691611 - PLATE
  • valve

20 6686312

  • 6686312 - SHIM

21 6686310

  • 6686310 - BEARING

22 6686316

  • 6686316 - PISTON
  • Was 6691464 - control

23 6691465

  • 6691465 - COLLAR

24 6691466

  • 6691466 - SPRING

25 6686318

  • 6686318 - COLLAR
  • spring

26 6686323

  • 6686323 - RING
  • RETAINER

27 6691609

  • 6691609 - SCREW

28 6691610

  • 6691610 - PIN

29 6686321

  • 6686321 - SCREW

30 6682878

  • 6682878 - PLUG
  • - Was 6686322

31 6691615

  • 6691615 - VALVE
  • relief

32 6691605

  • 6691605 - PISTON
  • brake

33 6691602

  • 6691602 - VALVE
  • poppet

34 6691604

  • 6691604 - SPRING
  • pressure

35 6691614

  • 6691614 - O-RING

36 6691606

  • 6691606 - SCREW
  • locking

37 6691603

  • 6691603 - COLLAR
  • spring

38 6691600

  • 6691600 - SPRING
  • pressure

39 6691613

  • 6691613 - O-RING

40 6691601

  • 6691601 - SCREW
  • locking

41 6688010

  • 6688010 - PIN

42 6686934

  • 6686934 - PIN

43 6676024

  • 6676024 - PLUG
  • Was 6691619

44 6686314

  • 6686314 - VALVE

45 6686304

  • 6686304 - SCREW
  • Was 6686935

46 6691618

  • 6691618 - ORIFICE
