WASHER 6536803 (10)

WASHER 6536803 (10)

WASHER 6536803 (10)

1 6536803

  • 6536803 - WASHER

2 62D4

  • 62D4 - NUT HEX FINISHED GR5

3 6631036

  • 6631036 - BALLJOINT

4 6672494

  • 6672494 - RING

5 6674264

  • 6674264 - RETAINER BOLT

6 6677904

  • 6677904 - BEARING
  • RH

7 6677908

  • 6677908 - BEARING
  • LH

8 29CM830

  • 29CM830 - SCREW HEX

9 6701174

  • 6701174 - WASHER FLAT

10 51DM10

  • 51DM10 - NUT HX THDLK PREAPPL

11 6804068

  • 6804068 - HANDLE ASSEMBLY
  • Also order Ref. 4

12 6808004

  • 6808004 - ROD

13 6809084

  • 6809084 - STOP
  • pedal

14 4DM8

  • 4DM8 - NUT HEX

15 6810303

  • 6810303 - SPACER

16 6810508

  • 6810508 - PEDAL
  • LH

17 6810511

  • 6810511 - PEDAL
  • RH

18 6810515

  • 6810515 - PLATE

19 6E8

  • 6E8 - WASHER

20 6810532

  • 6810532 - PEDAL
  • Use W/8 mm dia hardware

21 6810533

  • 6810533 - PEDAL
  • Use W/8 mm dia hardware

22 6812070

  • 6812070 - SEAL

23 6812286

  • 6812286 - PLATE
  • Use W/8 mm dia hardware

24 6812930

  • 6812930 - MOUNT

25 83D4

  • 83D4 - LKNUT HEX FLG GR8
  • .25" dia

26 51DM8

  • 51DM8 - NUT HX THDLK PREAPPL
  • 8 mm dia

27 17C416

  • 17C416 - BOLT
  • .25" dia

28 4CM825

  • 4CM825 - BOLT HEX HEAD
  • 8 mm dia - Was 1CM825

29 47DM8

  • 47DM8 - NUT HEX FLNG MPT

30 1CM1040

  • 1CM1040 - BOLT

31 1CM1220

  • 1CM1220 - BOLT

32 43DM8

  • 43DM8 - NUT FLANGED HEX

33 21CM1025

  • 21CM1025 - BOLT
  • carriage

34 25E22

  • 25E22 - WASHER
  • flat
