TANK 6564006 (1)

TANK 6564006 (1)

TANK 6564006 (1)

1 6564006

  • 6564006 - TANK

2 19K3

  • 19K3 - FITTING

3 6530858

  • 6530858 - HOSE
  • Was 6565085

4 6530861

  • 6530861 - HOSE
  • Was 6565080

5 6530860

  • 6530860 - HOSE
  • Was 6565079

6 18K7

  • 18K7 - FITTING
  • W/Ref. 7

7 79K10

  • 79K10 - O RING 10

8 6564153

  • 6564153 - ELBOW

9 17K3

  • 17K3 - ELBOW
  • W/Ref. 26

10 6530862

  • 6530862 - HOSE
  • 10'' (254 mm) - Was 6565084

11 6529344

  • 6529344 - HOSE
  • 14'' (355
  • 6 mm)

12 6594351

  • 6594351 - PULLEY
  • Use W/(2) of Ref. 12 (13G408 screw)

13 16G408

  • 16G408 - SCREW

14 13G408

  • 13G408 - SCREW

15 17C628

  • 17C628 - BOLT

16 57D6

  • 57D6 - NUT HEX FLNG GR8

17 79K12

  • 79K12 - O RING 10
  • Was 79K000016B

18 6564055

  • 6564055 - MOUNT

19 7172914

  • 7172914 - BRACKET
  • PUMP GEAR
  • Use W/ 7003484 pump

20 17C628

  • 17C628 - BOLT

21 85D8

  • 85D8 - NUT PRETRQ HEX LOCK

22 6560633

  • 6560633 - DAMPER
  • VIBRATION
  • rubber

23 6564692

  • 6564692 - WASHER

24 6565472

  • 6565472 - WASHER
  • .062" (1
  • 5748 mm) thick

25 6515817

  • 6515817 - WASHER
  • Use W/ 7003484 pump - .1793" (4
  • 554 mm) thick

26 25E21

  • 25E21 - WASHER FLAT PLAIN

27 17C844

  • 17C844 - BOLT

28 79K4

  • 79K4 - O RING 10

29 6594352

  • 6594352 - KEY
  • Use W/Ref. 11 (6594351 pulley)
