KIT, HEATER CAB FRESH AIR 6713379 (2)

KIT, HEATER CAB FRESH AIR 6713379 (2)

KIT, HEATER CAB FRESH AIR 6713379 (2)

1 6713379

  • 6713379 - KIT
  • HEATER CAB FRESH AIR
  • Ref. 2-39
  • 41-47 & 50-53

2 6660894

  • 6660894 - HARNESS
  • W/Ref. 46 & 47

3 6512067

  • 6512067 - GROMMET

4 6660879

  • 6660879 - ELBOW

5 42H10

  • 42H10 - HOSECLAM5
  • worm gear

6 5HM24

  • 5HM24 - CLAMP
  • constant tension

7 6660892

  • 6660892 - HARNESS

8 6660883

  • 6660883 - STRAP 10

9 6654191

  • 6654191 - VALVE

10 6660881

  • 6660881 - KNOB
  • water valve

11 6660884

  • 6660884 - SCREW

12 6660659

  • 6660659 - SWITCH
  • fan

13 6624435

  • 6624435 - NUT

14 6624435

  • 6624435 - NUT
  • W/Ref. 1 (6713379 Kit) - Was 6670143

15 6660822

  • 6660822 - KNOB

16 61D4

  • 61D4 - NUT 5

17 6670142

  • 6670142 - NUT
  • W/Ref. 1 (6713379 Kit)

18 4E4

  • 4E4 - WASHER

19 25E14

  • 25E14 - WASHER FLAT

20 6660893

  • 6660893 - SPACER
  • W/Ref. 1 (NLA/6709836 Kit)

21 17C424

  • 17C424 - BOLT
  • W/Ref. 19

22 17C416

  • 17C416 - BOLT
  • Use W/O Ref. 19

23 6670144

  • 6670144 - SCREW
  • Ref. 1 (6713379 Kit)

24 6641065

  • 6641065 - NUT

25 6641072

  • 6641072 - WASHER

26 6651975

  • 6651975 - SWITCH
  • RELAY MAGNETIC
  • relay

27 6670141

  • 6670141 - RELAY
  • relay - W/Ref. 1 (6713379 Kit)

28 6641066

  • 6641066 - SCREW

29 6850026

  • 6850026 - COVER
  • Also Order (2) of Ref. 41

30 6660864

  • 6660864 - COVER
  • W/O vent holes

31 6660930

  • 6660930 - T-SCREW

32 25E10

  • 25E10 - WASHER FLAT PLAIN

33 6660880

  • 6660880 - FILTER
  • AIR HEATER CAB

34 17C412

  • 17C412 - BOLT 5

35 6705792

  • 6705792 - BOLT

36 6660888

  • 6660888 - VENT
  • Use W/2.32 in. (58
  • 9 mm) wide blower housing - Ref. 26 - For Ref. 1(NLA/6709836 KIT)

37 6708914

  • 6708914 - REAR VENT
  • Use W/1.95 in. (49
  • 5 mm) wide blower housing - For Ref. 1 (NLA/6709836 KIT)

38 6657719

  • 6657719 - PLUG
  • 0.75" dia hole

39 17C516

  • 17C516 - BOLT

40 25E16

  • 25E16 - WASHER FLAT PLAIN

41 4E5

  • 4E5 - WASHER

42 61D5

  • 61D5 - NUT HEX FINISHED GR5

43 6660885

  • 6660885 - LOUVER

44 6660890

  • 6660890 - ASSY
  • COVER
  • Ref. 21-23 & 25 & 43

45 6660865

  • 6660865 - DECAL
  • fan & valve

46 889269

  • 889269 - HOSE BULK/FT
  • bulk - sold per foot

47 6702444

  • 6702444 - FUSE 25A 5

48 6657306

  • 6657306 - CAP
  • FUSE

49 84G3120

  • 84G3120 - SCREW

50 6711732

  • 6711732 - VENT
  • under seat - For Ref. 1 (NLA/6709836 Kit)

51 6669652

  • 6669652 - DUCT
  • under seat - For Ref. 1 (6713379 Kit) - Also Order (3) of Ref. 41

52 6669650

  • 6669650 - VENT SIDE
  • side - For Ref. 1 (6713379 Kit)

53 6674151

  • 6674151 - COVER

54 6724384

  • 6724384 - INSTRUCTIONS
  • Was 6722058
