HARNESS 6707665
1 6707665
- 6707665 - HARNESS
2 6711767
- 6711767 - HARNESS
- CAB BASE
- accomodates side console opt.
3 35C410
- 35C410 - SCREW HEX HD W/F GR5
4 30H56
- 30H56 - CLIP INSULATED
5 83D4
- 83D4 - LKNUT HEX FLG GR8
6 10C412
- 10C412 - BOLT
7 61D4
- 61D4 - NUT 5
8 30H29
- 30H29 - CLAMP
9 6665606
- 6665606 - SWITCH
- IGN
10 6674202
- 6674202 - NUT
- For Ref. 8 (6665606 Switch)
11 6598721
- 6598721 - NUT
- For Ref. 8 (NLA/6519592 Switch)
12 6512809
- 6512809 - KEYSET 10
- For Ref. 8 (NLA/6519592 Switch)
13 6693241
- 6693241 - KEY (2)
- ignition - single key W/O ring
14 6660594
- 6660594 - BUTTON
- on/off
15 6610510
- 6610510 - STRAP
- TIE 10
16 6706876
- 6706876 - HARNESS
17 6710313
- 6710313 - HARNESS
18 6708425
- 6708425 - PANEL
- L.H. - Was 6707658
19 6708426
- 6708426 - INSTPANEL
- L.H. - EUROPE
20 6712152
- 6712152 - INSTPANEL
- L.H. - accomodates side console option
21 6667903
- 6667903 - SWITCH
- AUX
- aux. controls module - W/4-spade connector - W/Ref. 11 - Was 6700603
22 6667904
- 6667904 - SWITCH
- aux. controls module - W/ 5-pin connector - W/Ref. 11
23 6667905
- 6667905 - SWITCH
- trac. override - Was 6706995
24 6674220
- 6674220 - SWITCH
- OVERRIDE TRACTION
- push to operate
25 6669225
- 6669225 - SCREW
- Was 58G000408B
26 6706896
- 6706896 - INSTR PNL
- R.H.
27 6665314
- 6665314 - PLUG ROCKER SW
28 6702642
- 6702642 - SCREW WSHRD PLASTITE
29 6669663
- 6669663 - GAUGE COOLANT TEMP
- eng temp - W/O clamp
30 6669664
- 6669664 - GAUGE VOLT
- W/O clamp
31 6669665
- 6669665 - GAUGE FUEL
- W/O clamp
32 91G412
- 91G412 - SCREW
- cross recess pan head
33 25G412
- 25G412 - SCREW SKT BTN HD CAP
- hex socket button head
34 6665318
- 6665318 - SWITCH
- glow plug - Was 6719038
35 6668927
- 6668927 - SWITCH
- glow plug
36 6636018
- 6636018 - LIGHT INDICATOR
- indicator
37 6664886
- 6664886 - METER HOUR
38 65G608
- 65G608 - SCREW PNH SLTD TAP
39 6578780
- 6578780 - CROSSMEMBER
40 6707664
- 6707664 - PLATE
- brake start - For Ref. 8 (NLA/6519592 Switch)
41 6709027
- 6709027 - PLATE 10
- For Ref. 8 (6665606 Switch) - Was 6708693
42 6680411REM
- 6680411REM - CONTROLLER
- PEDALS FOOT BICS
43 6680445
- 6680445 - CONTROLER
- AHC - Was 6674224
44 6680411
- 6680411 - CONTROLLER
- PEDALS FOOT BICS
- foot pedals - Was 6674222
45 6707674
- 6707674 - PLUG HOLE
- round - plugs 1.28" (32
- 5 mm) dia. hole in cab
46 6665321
- 6665321 - RIVET PLASTIC MALE
- plastic male
47 6665322
- 6665322 - RIVET PLASTIC FEMALE
- plastic female
48 6665000
- 6665000 - BRACKET MOUNTING
49 6665527
- 6665527 - TIE
- never modify
50 6664584
- 6664584 - CONNECTOR
- Also Order (20) of & (4) of Ref. 39 - Was 6665683
51 6664827
- 6664827 - PIN
52 6664040
- 6664040 - PIN 5
53 6724282
- 6724282 - KIT
- SWITCH IGN
- Ref. 8
- 10 & 30
54 6712134
- 6712134 - HARNESS
- CONTROLLER
55 6710312
- 6710312 - HARNESS
56 6706828
- 6706828 - HARNESS
57 6668814
- 6668814 - SWITCH
- bucket position on-off
58 6599696
- 6599696 - SOCK AND BULB
- assy.
59 895771
- 895771 - #161 BULB
60 6712523
- 6712523 - HARNESS
- for BICS combo control valve
