KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

1 6712820

  • 6712820 - KIT
  • ELECTRICAL CONTROLS
  • controls - W/handles - Ref. 2-30 & 42 - SEE NOTE

2 6680413

  • 6680413 - HANDLE
  • SWITCH DLX
  • RH - multi switch - Also Order Ref. 4
  • 5
  • 7 & 8 - Was 6706340

3 6680457

  • 6680457 - HNDL/4 SWITCH PWM
  • R.H. - Also Order Ref. 7
  • 8
  • 38 & 39 - PWM - Was 6675466

4 6640690

  • 6640690 - PIN

5 6641176

  • 6641176 - SEAL

6 6640690

  • 6640690 - PIN
  • PWM

7 6641176

  • 6641176 - SEAL
  • PWM

8 6662257

  • 6662257 - PIN
  • PWM

9 6680412

  • 6680412 - HANDLE DLX LEFT
  • L.H. - Also Order Ref. 4
  • 5 & 9-11 - Was 6707976

10 6640690

  • 6640690 - PIN

11 6640691

  • 6640691 - TERMINAL

12 6641176

  • 6641176 - SEAL

13 6662257

  • 6662257 - PIN

14 6680447

  • 6680447 - DECAL
  • Was 6677370

15 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

16 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

17 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector - PWM

18 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector

19 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin

20 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin - PWM

21 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin - PWM

22 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin

23 6664036

  • 6664036 - NUT

24 6641181

  • 6641181 - LOCK
  • 6-pin

25 6641173

  • 6641173 - CONNECTOR
  • 6-pin

26 6641178

  • 6641178 - CONNECTOR METRI PACK
  • 2-pin

27 6664800

  • 6664800 - LOCK SECONDARY
  • 3-pin triangle

28 6664599

  • 6664599 - CONNECTOR 3 PIN
  • 3-pin triangle

29 6710299

  • 6710299 - HARNESS
  • ATTACHMENT PWM

30 6711621

  • 6711621 - MOUNT
  • box shaped

31 6714999

  • 6714999 - MOUNT
  • flat - one hole for harness

32 6624289

  • 6624289 - STRAP
  • TIE
  • Was 6610510

33 6664035

  • 6664035 - CAP

34 45G508

  • 45G508 - BOLT

35 50D5

  • 50D5 - NUT

36 84G3712

  • 84G3712 - SCREW THD ROLLING TT

37 6706552

  • 6706552 - HARNESS
  • for grader

38 45G1212

  • 45G1212 - BOLT

39 50D12

  • 50D12 - NUT

40 6664040

  • 6664040 - PIN 5

41 6664041

  • 6664041 - PIN 10

42 6670312

  • 6670312 - SWITCH
  • MAGNETIC
  • relay - Was 6665005

43 6664388

  • 6664388 - DIODE
  • memory

44 6702650

  • 6702650 - MOUNT FUSE

45 6717863

  • 6717863 - MOUNT FUSE

46 6706446

  • 6706446 - HARNESS

47 6649028

  • 6649028 - CONNECTOR

48 6665001

  • 6665001 - CONNECTOR
  • ELECTRICAL
  • W/Ref. 43 - not in kits - also Order (6) of Ref. 23 - Was 6664034

49 6667569

  • 6667569 - CONNECTOR
  • RECEPTACLE
  • W/Ref. 43 - Also Order (14) of Ref. 22 - Was 6664039

50 6664181

  • 6664181 - CONNECTOR
  • not in kits

51 6664182

  • 6664182 - CONNECTOR
  • not in kits

52 6706392

  • 6706392 - HARNESS
  • not in kits - connects old loader harness to new attachment harness - W/Ref. 30 & 34

53 6706391

  • 6706391 - HARNESS
  • not in kits - connects new loader harness to old attachment harness - W/Ref. 31 & 32

54 6664037

  • 6664037 - WASHER

55 6706568

  • 6706568 - KIT
  • HANDLE
  • handle - Ref. 3-5 & 9-11 & 40

56 6706567

  • 6706567 - KIT
  • HANDLE DLX RH
  • handle - W/Ref. 4
  • 5
  • 7
  • 8 & 40

57 6706735

  • 6706735 - KIT
  • HANDLE DLX
  • handle - W/Ref. 7
  • 8 & 38-40 - PWM

58 6662246

  • 6662246 - CONNECTOR
  • 6-pin - PWM

59 6662252

  • 6662252 - LOCK
  • 6-pin - PWM

60 6722759

  • 6722759 - INSTRUCTIONS
  • for Ref. 3-36

61 6722758

  • 6722758 - INSTRUCTIONS
  • for control elec. kit

62 6710300

  • 6710300 - HARNESS

63 6669286

  • 6669286 - CLAMP
  • W/ saddles

64 45G1212

  • 45G1212 - BOLT

65 25E6

  • 25E6 - WSHR

66 84G3110

  • 84G3110 - SCREW
  • Was 84G003112B

67 6716799

  • 6716799 - KIT
  • AUX
  • dual function aux. - Ref. 48-52

68 6716844

  • 6716844 - HARNESS
  • jumper

69 6670312

  • 6670312 - SWITCH
  • MAGNETIC
  • relay

70 6716798

  • 6716798 - HARNESS
  • KP diverter

71 6624289

  • 6624289 - STRAP
  • TIE

72 6900601

  • 6900601 - INSTRUCTIONS
