STRAP, TIE 6624289 (15)

STRAP, TIE 6624289 (15)

STRAP, TIE 6624289 (15)

1 6624289

  • 6624289 - STRAP
  • TIE

2 6667170

  • 6667170 - PUMP
  • PRIMER HAND

3 6701449

  • 6701449 - FLR.TUBE

4 7015668

  • 7015668 - MOUNT
  • STRAP TIE

5 7023550

  • 7023550 - CAP
  • DIESEL LOCKING

6 7106279

  • 7106279 - SCREW

7 7172473

  • 7172473 - HOSE
  • FUEL

8 7172474

  • 7172474 - HOSE
  • INLET

9 7188104

  • 7188104 - FITTING
  • FUEL ELBOW

10 7213054

  • 7213054 - FITTING
  • ELBOW

11 7226644

  • 7226644 - BRACKET
  • FILTER

12 7227060

  • 7227060 - BRACKET
  • TANK FUEL

13 7228056

  • 7228056 - INSULATION
  • TANK FUEL

14 7237463

  • 7237463 - HOSE
  • FUEL BULK
  • sold per foot

15 7237139

  • 7237139 - GROMMET

16 29CM1020

  • 29CM1020 - SCREW HEX 10MMX20MM

17 42H56

  • 42H56 - CLAMP

18 42HS04

  • 42HS04 - CLAMP HOSE TYPE M

19 5HM14

  • 5HM14 - HOSE CLMP CONST TENS

20 5HM23

  • 5HM23 - HOSE CLMP CONST TENS

21 5HM58

  • 5HM58 - CLAMP

22 6577822

  • 6577822 - HOSE BULK
  • sold per foot

23 7273691

  • 7273691 - GROMMET
  • Use W/ 19
  • 05 mm (0.75") dia hole

24 6599645

  • 6599645 - PLUG
  • STEEL

25 7172472

  • 7172472 - TANK
  • FUEL
  • Also order 7227060 bracket when replacing fuel tank

26 6717579

  • 6717579 - GASKET

27 7286464

  • 7286464 - SENSOR
  • FUEL
  • Was 7179839

28 6666302

  • 6666302 - ELBOW BARBED

29 6683892

  • 6683892 - TUBE
  • FUEL

30 7013579

  • 7013579 - FILTER FUEL ASSY
  • W/Ref. 4

31 7023589

  • 7023589 - FILTER FUEL W/SEPARATOR

32 7231900

  • 7231900 - EXCHANGER
  • FUEL

33 7225113

  • 7225113 - BRACKET
  • MOUNTING

34 28CM820

  • 28CM820 - BOLT CARRIAGE 8.8

35 43DM8

  • 43DM8 - NUT FLANGED HEX

36 7140157

  • 7140157 - TEE

37 7302578

  • 7302578 - VALVE BYPASS
  • Was 7275950

38 7231187

  • 7231187 - CONNECTOR

39 7189953

  • 7189953 - FUEL
  • TUBE
  • W/Ref. 14
  • 34
  • &37
