New Holland Construction
/
(C227) - COMPACT TRACK LOADER (4/11-)
/
KIT 84424042

KIT 84424042

KIT 84424042

1 84424042

  • 84424042 - KIT
  • DIA Kit
  • EU Road Lights
  • MD
  • RAD
  • NH
  • Incl. 1-39

2 280476

  • 280476 - SELF-TAP SCREW
  • HWH
  • 3/8"-16 x 1"

3 9804255

  • 9804255 - BOLT
  • Hex
  • M6 x 1 x 16mm
  • Full Thd
  • Cl 8.8

4 9804276

  • 9804276 - FLANGE NUT
  • Hex
  • M6 x 1
  • Cl 8

5 9821783

  • 9821783 - FLASHER UNIT
  • A

6 84262451

  • 84262451 - WIRE HARNESS
  • FE Boom RD

7 84262455

  • 84262455 - WIRE HARNESS
  • Rear
  • Road Jumper

8 84263153

  • 84263153 - SWITCH
  • Rocker
  • Loader Lockout

9 84306584

  • 84306584 - BRACKET
  • SUPPORTING
  • Light
  • LH
  • Gray

10 84306586

  • 84306586 - BRACKET
  • SUPPORTING
  • Light
  • RH
  • Gray

11 86511042

  • 86511042 - SCREW
  • Pan Head
  • M4 x 0.7 x 16mm
  • Cl 4.8

12 82035642

  • 82035642 - HEADLAMP
  • 12V
  • 50W
  • Clear
  • Work

13 84335806

  • 84335806 - HOUSING
  • RH
  • W/O Turn Signal

14 84335748

  • 84335748 - SCREW
  • FLAT
  • M8 x 19.809mm
  • Light Round

15 84335810

  • 84335810 - HOUSING
  • LH
  • W/O Turn Signal

16 84333233

  • 84333233 - BRACKET

17 87682398

  • 87682398 - SCREW
  • Torx
  • Round HD
  • M6 x 16mm
  • Cl 10.9

18 84335751

  • 84335751 - NUT
  • #10-16
  • Grommet

19 84173781

  • 84173781 - SELF-TAP SCREW
  • Phillips Drive
  • Pan HD
  • #10 - 16 x 5/8"
  • 10-16 X 5/8

20 86900239

  • 86900239 - SPRING NUT
  • U
  • #10 - 24
  • 10-24

21 87307791

  • 87307791 - SCREW
  • Phillips Drive
  • Pan HD
  • #10 x 24 x 1/2"
  • 10-24 X 1/2

22 84331370

  • 84331370 - WIRE HARNESS
  • Lamp Jumper
  • Front

23 9804277

  • 9804277 - FLANGE NUT
  • Hex
  • M8 x 1.25
  • Cl 8

24 87627854

  • 87627854 - LIGHT ASSY.
  • 12V
  • 27W
  • Red
  • Rear
  • Stop-Tail

25 86502967

  • 86502967 - SCREW
  • Phillips Drive
  • Pan HD
  • M5 x 30mm
  • Cl 4.8

26 86512420

  • 86512420 - CARRIAGE BOLT
  • Rnd Head
  • M8 x 1.25 x 20mm
  • Full Thd
  • Cl 8.8

27 86512495

  • 86512495 - FLANGE NUT
  • Hex
  • M5
  • Cl 8

28 87629587

  • 87629587 - LIGHT ASSY.
  • 12V
  • 27W
  • Amber
  • Warning

29 84419629

  • 84419629 - BRACKET
  • RR
  • Road Light
  • Yellow

30 84416164

  • 84416164 - FOAM INSULATION
  • RH Upper Chassis

31 86589143

  • 86589143 - SPACER
  • 9.5mm ID x 15.9mm OD x 12.7mm L
  • A

32 86604657

  • 86604657 - INDICATOR
  • TURN SIGN

33 86625035

  • 86625035 - CLAMP
  • 12.7mm
  • Coat
  • 7.1mm Bolt Hole
  • P Type

34 87016557

  • 87016557 - SELF-TAP SCREW
  • Hex
  • M8 x 1.25 x 25mm

35 87572859

  • 87572859 - LAMP
  • EU Boom
  • Right

36 87572860

  • 87572860 - LAMP
  • EU Boom
  • Left

37 87634133

  • 87634133 - SWITCH
  • Hazard Lights

38 87668737

  • 87668737 - CABLE TIE
  • 203.2mm L
  • Nylon
  • Fir Tree Assembly

39 R45966

  • R45966 - CLAMP
  • 0.94mm
  • Coat
  • 90 Degree Twist
  • 90 Degree
  • Twist

40 84424227

  • 84424227 - INSTRUCTION
  • Instruction Sheet
  • EU Road Lights (C227)
