SHACKLE 102256901CC

SHACKLE 102256901CC

SHACKLE 102256901CC

1 102256901CC

  • 102256901CC - SHACKLE
  • rear spring

2 8754CC

  • 8754CC - LOCKNUT
  • 3/8-16 HEX

3 1012303CC

  • 1012303CC - BUSHING
  • STEEL

4 7247581

  • 7247581 - BUSHING
  • URETHANE
  • Was 1015583CC

5 1010145CC

  • 1010145CC - NUT
  • 3/8-24 HEX

6 102267301CC

  • 102267301CC - ABSORBER
  • rear

7 1011415CC

  • 1011415CC - SHOCK ABSORBER CUSHION KIT
  • shock absorber - W/Ref. 8-9

8 102258801CC

  • 102258801CC - U - BOLT

9 102006501CC

  • 102006501CC - SPRING
  • XRT REAR LEAF SPRING

10 102066201CC

  • 102066201CC - SCREW

11 102266301CC

  • 102266301CC - REINFORCED SPRING PAD
  • spring

12 7270CC

  • 7270CC - BOLT
  • 3/8-16 X 4.50 HEX HEAD

13 808CC

  • 808CC - WASHER
  • 3/8 TYPE B FLAT

14 1015453CC

  • 1015453CC - COMPRESSION MOUNT
  • compression

15 102045601CC

  • 102045601CC - SPACER .38 ID X .500 OD

16 101900802CC

  • 101900802CC - HANGER

17 102065001CC

  • 102065001CC - LOCKNUT 7/16-14 FLANGE DIMPLE
