SUB ASSEMBLY ACCELERATOR PEDAL 1017696CC

SUB ASSEMBLY ACCELERATOR PEDAL 1017696CC

SUB ASSEMBLY ACCELERATOR PEDAL 1017696CC

1 1017696CC

  • 1017696CC - SUB ASSEMBLY ACCELERATOR PEDAL
  • pedal assy - W/Ref. 2-3 - Was 1017696CC

2 1013871CC

  • 1013871CC - PAD
  • ACCELERATOR PEDAL
  • pedal

3 1624CC

  • 1624CC - SCREW
  • 3/8-16 X 1.50 HX HD CAP

4 1241CC

  • 1241CC - WASHER
  • 5/16 TYPE A FLAT

5 102026001CC

  • 102026001CC - KIT
  • ACCELERATION PIVOT ROD
  • accelerator pivot rod

6 1011700CC

  • 1011700CC - SPACER ASSEMBLY

7 7473CC

  • 7473CC - LOCKNUT
  • 5/16-18 NYLON INSERT

8 332CC

  • 332CC - WASHER
  • 1/4 TYPE A NARROW FLAT

9 1017424CC

  • 1017424CC - BEARING
  • PIVOT SUPPORT

10 8717CC

  • 8717CC - LOCKNUT
  • 1/4-28 NYLON INSERT
  • Was 101966901CC

11 101817401CC

  • 101817401CC - RETAINER
  • SPRING

12 101796201CC

  • 101796201CC - SPRING
  • ACCELERATOR RETURN

13 1017378CC

  • 1017378CC - CUP

14 1017380CC

  • 1017380CC - BUMPER
  • SPRING RETURN

15 8233CC

  • 8233CC - LOCKNUT
  • 1/4-20 NYLON INSERT

16 101818801CC

  • 101818801CC - STUD
  • 1/4-28 X 1.35 BALL

17 101674702CC

  • 101674702CC - ROD ASSEMBLY
  • accelerator - W/Ref. 19-20 - 2100S

18 101822001CC

  • 101822001CC - ROD ACCELERATOR ASSEMBLY
  • accelerator - W/Ref. 19-20 - 2100

19 1011084CC

  • 1011084CC - NUT
  • 1/4-28 HEX JAM

20 1011734CC

  • 1011734CC - JOINT
  • BALL

21 1011694CC

  • 1011694CC - BRACKET ACCELERATION ASSEMBLY
  • accelerator pivot rod

22 101861901CC

  • 101861901CC - SCREW
  • 1/4-20 X 1.125 HEX CAP

23 8754CC

  • 8754CC - LOCKNUT
  • 3/8-16 HEX

24 101916901CC

  • 101916901CC - RATCHET SUPPT (POA ON 1019185)

25 334CC

  • 334CC - WASHER
  • 3/8 TYPE A FLAT
