PEDAL
1 6589985
- 6589985 - PEDAL
- LH
2 6537481
- 6537481 - MOUNT
- Pivot
3 58K015
- 58K015 - O-RING 10
4 6536545
- 6536545 - SLEEVE
5 1CM1055
- 1CM1055 - BOLT
6 6536802
- 6536802 - WASHER
7 27E6
- 27E6 - WASHER HARDEN PLAIN
8 53DM10
- 53DM10 - NUT HX THDLK PREAPPL
- Was 49DM00010B
9 6536531
- 6536531 - BRG ROD E
10 4DM10
- 4DM10 - NUT HEX
- Was 1DM00010B
11 6586636
- 6586636 - ROD
12 6587431
- 6587431 - NUT
- LH thread
13 6587430
- 6587430 - YOKE
- LH thread
14 6536543
- 6536543 - PIN
15 1F212
- 1F212 - PIN
16 6587171
- 6587171 - MOUNT
17 29CM1020
- 29CM1020 - SCREW HEX 10MMX20MM
18 29CM1025
- 29CM1025 - SCREW FLGD HEX CAP
19 6801466
- 6801466 - SHAFT
20 14J2124
- 14J2124 - ROLLPIN
21 6589986
- 6589986 - SPACER
22 6536818
- 6536818 - BEARING
23 4CM816
- 4CM816 - SCREW HEX HD 8.8
- Was 1CM816
24 6586658
- 6586658 - PLATE
- Mounting
25 6587429
- 6587429 - ROD
26 6536801
- 6536801 - BUSHING
27 6586633
- 6586633 - LEVER
28 6536831
- 6536831 - BELLCRANK
29 6801463
- 6801463 - SPACER
30 6801465
- 6801465 - ROD
- L.H.
31 6801464
- 6801464 - SPACER
32 6536803
- 6536803 - WASHER
- Wave Spring
33 6587183
- 6587183 - LEVER
34 4DM8
- 4DM8 - NUT HEX
- Was 1DM00008B
35 6586635
- 6586635 - ROD
36 53DM8
- 53DM8 - NUT HX THDLK PREAPPL
- Was 49DM00008B
37 6586653
- 6586653 - MOUNT
- Pedal Lock/Foot Rest
38 26GM8016
- 26GM8016 - SCREW SELF TAPPING
39 6586654
- 6586654 - PLATE
40 6537640
- 6537640 - PLATE
41 1CM885
- 1CM885 - BOLT
42 1CM8100
- 1CM8100 - SCREW HEX CAP
43 6589584
- 6589584 - PEDAL
- RH
44 26GM10020
- 26GM10020 - SCREW HEX THRDRLG
45 6801462
- 6801462 - LEVER
