Главная
/
Бренды
/
Bobcat
/
3200
/
BOLT 7016152

BOLT 7016152

BOLT 7016152

1 7016152

  • 7016152 - BOLT

2 7016365

  • 7016365 - DISC
  • BRAKE
  • REAR
  • 8.625X.188

3 7016719

  • 7016719 - STUD
  • 3/8
  • 24X1.38
  • PRESS FIT
  • Z

4 7016455

  • 7016455 - HUB
  • WHEEL
  • REAR
  • MACH
  • BLK

5 7016834

  • 7016834 - WHEEL
  • REAR ORANGE
  • 12 X 8

6 7019208

  • 7019208 - TIRE
  • ALL TERRAIN REAR 25X12X8
  • 4 PLY
  • 12 PSI max - Carlisle 589531

7 7027147

  • 7027147 - TIRE
  • 25X11.00-12NHS 4PR
  • 22 PSI max - Carlisle 560414

8 7016772

  • 7016772 - WASHER

9 7016496

  • 7016496 - NUT

10 7016759

  • 7016759 - WASHER
  • CONE

11 7016523

  • 7016523 - NUT

12 7016743

  • 7016743 - VALVE
  • RIM

13 7016540

  • 7016540 - PIN
  • COTTER

14 7016452

  • 7016452 - HUB
  • DUST COVER

15 6989066

  • 6989066 - TIRE
  • TURF 25 X 11.00 X 12 4 PLY

16 7248684

  • 7248684 - WHEEL
  • RIM
  • 8 spoke

17 6989002

  • 6989002 - CAP
  • CENTER WHEEL

18 6988433

  • 6988433 - STEM
  • VALVE CHROME

19 6989003

  • 6989003 - NUT
  • WHEEL CHROME

20 7027145

  • 7027145 - TIRE STREET
  • street
