337.0
/
TEE 6587567 (2)

TEE 6587567 (2)

TEE 6587567 (2)

1 6587567

  • 6587567 - TEE
  • W/Ref. 24

2 52E404

  • 52E404 - ADAPTER
  • W/Ref. 22 & 23

3 15KB0404

  • 15KB0404 - FTG HYD S CONNECTOR

4 15KB0404

  • 15KB0404 - FTG HYD S CONNECTOR

5 97K4

  • 97K4 - O'RING
  • Flare end

6 6802575

  • 6802575 - ADAPTER
  • W/Ref. 24
  • 25

7 6628709

  • 6628709 - MANIFOLD
  • Pump

8 6587446

  • 6587446 - TEE
  • W/Ref. 24

9 6628907

  • 6628907 - TEE
  • W/Ref. 27

10 6628728

  • 6628728 - TANK
  • hydraulic - Was 6628727

11 6669587

  • 6669587 - CLAMP

12 6804032

  • 6804032 - BRACKET
  • Hydraulic Tank - Was 6628915

13 6630367

  • 6630367 - CAP
  • Dust

14 6674785

  • 6674785 - PUMP
  • HYD

15 6806937

  • 6806937 - HOSE
  • Was 6669457

16 6803290

  • 6803290 - HOSE

17 6803290

  • 6803290 - HOSE

18 6805843

  • 6805843 - HOSE

19 6805843

  • 6805843 - HOSE

20 6800727

  • 6800727 - HOSE

21 6805841

  • 6805841 - HOSE

22 6805841

  • 6805841 - HOSE

23 6800728

  • 6800728 - HOSE

24 7000009

  • 7000009 - PLUG
  • Diagnostic

25 6672281

  • 6672281 - CLAMP
  • Was 5HM00035B

26 42HC250

  • 42HC250 - CLAMP
  • - Was 6671626

27 19J16

  • 19J16 - FLANGE
  • Split Flange

28 19J24

  • 19J24 - CLAMP
  • Split Flange

29 58K11

  • 58K11 - O RING 10

30 79K4

  • 79K4 - O RING 10
  • flat boss face

31 99K4

  • 99K4 - O-RING
  • tapered boss face

32 79K10

  • 79K10 - O RING 10

33 58K018

  • 58K018 - O-RING 10

34 79K6

  • 79K6 - O RING 10

35 79K32

  • 79K32 - O RING 10

36 6800438

  • 6800438 - HOSE

37 6630168

  • 6630168 - COUPLER
  • DIAGNOSTIC
  • Diagnostic - W/Ref. 26

38 75E1212

  • 75E1212 - TEE
  • W/Ref. 25

39 63E12

  • 63E12 - CAP

40 6667807

  • 6667807 - COUPLER
  • FEMALE
  • For testing purposes only - not included W/Excavator

41 6802442

  • 6802442 - HOSE

42 86F3

  • 86F3 - NUT 10
  • bulkhead

43 90F3

  • 90F3 - TEE
  • bulkhead

44 6802258

  • 6802258 - HOSE

45 6803091

  • 6803091 - HOSE

46 6800440

  • 6800440 - HOSE

47 6800665

  • 6800665 - HOSE

48 6800436

  • 6800436 - HOSE

49 75E404

  • 75E404 - TEE

50 17K7

  • 17K7 - ELBOW
  • W/Ref.

51 6669585

  • 6669585 - COUPLER
  • Diagnostic

52 6715715

  • 6715715 - ADAPTER
  • W/Ref. 53 - Was 6805715

53 6805839

  • 6805839 - FITTING

54 6802775

  • 6802775 - ADAPTER
  • W/Ref. 24

55 17C620

  • 17C620 - BOLT

56 58K219

  • 58K219 - O RING 10

57 58K225

  • 58K225 - O RING 10

58 17C824

  • 17C824 - BOLT 5
  • Was 17K000824B

59 4E8

  • 4E8 - WASHER

60 78E1212

  • 78E1212 - ADAPTER
  • W/Ref. 53 - for testing purposes

61 99K12

  • 99K12 - O-RING
  • Was 79K000012B

62 15K3

  • 15K3 - CONNECTOR HYDRAULIC SHORT

63 6653493

  • 6653493 - COVER

64 30H35

  • 30H35 - CLIP INSULATED

65 1CM885

  • 1CM885 - BOLT

66 51DM8

  • 51DM8 - NUT HX THDLK PREAPPL

67 4CM1235

  • 4CM1235 - BOLT
  • pump mounting - Was 1CM1235
