GRIP HANDLE 6513963 (2)
1 6513963
- 6513963 - GRIP HANDLE
2 6502635
- 6502635 - LEVER
- splined shaft
3 62D6
- 62D6 - NUT HEX FINISHED GR5
4 6E6
- 6E6 - WASHER
- shakeproof
5 18C624
- 18C624 - BOLT
6 10H35
- 10H35 - FTG GREASE STRAIGHT
7 6502630
- 6502630 - MT/NUT
- steering
8 25K40028
- 25K40028 - O RING 10
9 6502291
- 6502291 - BUSHING
10 6504707
- 6504707 - SHAFT
- splined
11 6502340
- 6502340 - SCREW
- shoulder
12 81D6
- 81D6 - NUT
13 6505076
- 6505076 - SPRING
14 6544654
- 6544654 - BUSHING
15 6515316
- 6515316 - WASHER
- spring
16 6540478
- 6540478 - RACE
- thrust - See Note
17 6540559
- 6540559 - NUT KIT
- actuating - R.H. thread - W/Ref. 18 - SEE NOTE
18 6540558
- 6540558 - NUT KIT
- actuating - L.H. thread - W/Ref. 18 - SEE NOTE
19 6502415
- 6502415 - PIN
- clutch
20 5J405
- 5J405 - KEY
- woodruff
21 6502312
- 6502312 - THREAD
- R.H.
22 6505041
- 6505041 - WASHER
- flat
23 5E14
- 5E14 - WASHER
- shakeproof
24 62D14
- 62D14 - NUT
