KIT, WINDOW SIDE 7128342

KIT, WINDOW SIDE 7128342

KIT, WINDOW SIDE 7128342

1 7128342

  • 7128342 - KIT
  • WINDOW SIDE
  • Ref. 2-16

2 7148068

  • 7148068 - WINDOW ASSY
  • RH - W/Ref. 10-13

3 7148069

  • 7148069 - WINDOW ASSY
  • LH - W/Ref. 10-13

4 35C412

  • 35C412 - SCREW FLGD HEX CAP

5 7154910

  • 7154910 - INSERT
  • THREADED

6 7010357

  • 7010357 - CAP
  • END

7 7010358

  • 7010358 - SPRING

8 7010359

  • 7010359 - KNOB

9 7010360

  • 7010360 - SLEEVE

10 7010365

  • 7010365 - NUT

11 7254421

  • 7254421 - BUMPER

12 6987228ENUS

  • 6987228ENUS - INSTRUCTIONS
  • Was 6987228

13 7265242ENUS

  • 7265242ENUS - INSTRUCTIONS
