New Holland Construction
/
(575E) - TRACTOR LOADER BACKHOE (1/96-)
/
RING 9969070 (2)

RING 9969070 (2)

RING 9969070 (2)

1 9969070

  • 9969070 - RING

2 9970010

  • 9970010 - BEARING

3 9969085

  • 9969085 - WASHER

4 9969078

  • 9969078 - BALL BEARING
  • 45mm ID x 75mm OD x 16mm W

5 9969076

  • 9969076 - SNAP RING

6 85808359

  • 85808359 - GEAR

7 9969077

  • 9969077 - BEARING

8 9969057

  • 9969057 - RING

9 85808343

  • 85808343 - BACKING PLATE

10 9969073

  • 9969073 - SPRING

11 85811878

  • 85811878 - HALF-DISC

12 85808338

  • 85808338 - HALF-DISC

13 85811880

  • 85811880 - CLUTCH PLATE

14 85808340

  • 85808340 - CLUTCH PLATE

15 85811879

  • 85811879 - DISC

16 85808339

  • 85808339 - DISC
