New Holland Construction
/
(575E) - TRACTOR LOADER BACKHOE (1/96-)
/
WIPER MOTOR,12V

WIPER MOTOR,12V

WIPER MOTOR,12V

1 85801838

  • 85801838 - WIPER MOTOR
  • 12V

2 85806097

  • 85806097 - WIPER MOTOR

3 76011644

  • 76011644 - WIPER ARM
  • Single
  • 400mm L

4 85806098

  • 85806098 - WIPER ARM
  • Single
  • 513mm L

5 85801985

  • 85801985 - WIPER BLADE
  • 513mm L

6 85806099

  • 85806099 - WIPER BLADE

7 85801839

  • 85801839 - GUARD

8 12638104

  • 12638104 - WASHER
  • 5.2mm ID x 14mm OD x 1mm Thk

9 85801842

  • 85801842 - GUARD

10 13276217

  • 13276217 - SCREW
  • Pozidriv Pan Hd
  • M6 x 16mm
  • Cl 5.8
  • Full Thd

11 9969458

  • 9969458 - COVER

12 85806095

  • 85806095 - COVER
