New Holland Construction
/
(B110C) - BACKHOE LOADER - TIER 4A (3/12-)
/
PANEL 87410385 (1)

PANEL 87410385 (1)

PANEL 87410385 (1)

1 87410385

  • 87410385 - PANEL

2 10519604

  • 10519604 - WASHER
  • 8.15mm ID x 17mm OD x 2mm Thk

3 16043824

  • 16043824 - SCREW
  • Hex
  • M8 x 1.25 x 30mm
  • Cl 8.8
  • Full Thd
  • DAC

4 84478022

  • 84478022 - BULKHEAD

5 84498262

  • 84498262 - GROMMET
  • 80mm L
  • 90mm L
  • 30mm L

6 84423177

  • 84423177 - MOUNTING PLATE

7 86625180

  • 86625180 - SCREW
  • HEX
  • 10-24X3/4 x 0.75 TT HWHD ZND
