(B110C) - BACKHOE LOADER - TIER 4A (3/12-)
/
RETAINER,300mm L x 1mm Thk

RETAINER,300mm L x 1mm Thk

RETAINER,300mm L x 1mm Thk

1 85812364

  • 85812364 - RETAINER
  • 300mm L x 1mm Thk

2 13276217

  • 13276217 - SCREW
  • Pozidriv Pan Hd
  • M6 x 16mm
  • Cl 5.8
  • Full Thd

3 16105111

  • 16105111 - LOCK NUT
  • M12 x 1.25
  • Cl 8

4 12646904

  • 12646904 - WASHER
  • 12.2mm ID x 28mm OD x 3mm Thk

5 85801814

  • 85801814 - SPACER
  • 12.5mm ID x 30mm OD x 0.5mm Thk

6 85801815

  • 85801815 - BUSHING
  • 12mm ID x 14mm OD x 20mm L

7 12574215

  • 12574215 - NUT
  • M6 x 1
  • Cl 8

8 14496407

  • 14496407 - WASHER
  • 6.4mm ID x 12.5mm OD x 1.6mm Thk

9 11198074

  • 11198074 - BELLEVILLE WASHER
  • M8 Bolt Size x 15mm OD x 1.8mm Thk

10 15811387

  • 15811387 - CAP
  • M10 x 13.5

11 85801827

  • 85801827 - GAS STRUT

12 85801812

  • 85801812 - SUPPORT

13 85801813

  • 85801813 - SUPPORT

14 12647004

  • 12647004 - WASHER
  • 8.15mm ID x 25mm OD x 2.5mm Thk

15 85801816

  • 85801816 - SUPPORT

16 16104111

  • 16104111 - NUT
  • Prevailing Torque
  • M8
  • 1.25 Pitch
  • 10.6mm High
  • Cl 08
  • ZND

17 5132136

  • 5132136 - CAP COVER
  • M8

18 12638504

  • 12638504 - WASHER
  • 8.15mm ID x 15mm OD x 1.5mm Thk

19 14306424

  • 14306424 - HEX SOC SCREW
  • M8 x 1.25 x 25mm
  • Cl 8.8
  • Full Thd
