(B110C) - BACKHOE LOADER - TIER 4B (2/15-)
/
PILOT VALVE 47765051 (2)

PILOT VALVE 47765051 (2)

PILOT VALVE 47765051 (2)

1 47765051

  • 47765051 - PILOT VALVE

2 85828004

  • 85828004 - BODY

3 14358921

  • 14358921 - HEX SOC SCREW
  • M5 x 50mm
  • Cl 8.8

4 14302921

  • 14302921 - HEX SOC SCREW
  • M4 x 10mm
  • Cl 8.8
  • Full Thd

5 NSS

  • NSS - NOT SOLD SEPARAT

6 85828000

  • 85828000 - SEAL KIT

7 85827993

  • 85827993 - SOLENOID VALVE

8 NSS

  • NSS - NOT SOLD SEPARAT

9 47773975

  • 47773975 - MANIFOLD VALVE
