Bobcat
/
542
/
COIL 6640706

COIL 6640706

COIL 6640706

1 6640706

  • 6640706 - COIL
  • assy.

2 6649562

  • 6649562 - STRAP

3 6649563

  • 6649563 - SCREW

4 6649564

  • 6649564 - NUT

5 6649568

  • 6649568 - WIRE
  • spark plug #2

6 6649569

  • 6649569 - WIRE
  • spark plug #3

7 6649570

  • 6649570 - WIRE
  • spark plug #1

8 6649571

  • 6649571 - WIRE
  • spark plug #4

9 6649572

  • 6649572 - SPARK PLUG-4

10 6630392

  • 6630392 - CAP
  • DISTRIBUTOR

11 6646537

  • 6646537 - ROTOR

12 6646540

  • 6646540 - PIN

13 6646542

  • 6646542 - MODULE
  • ignition
