SEAT 6655155 (2)

SEAT 6655155 (2)

SEAT 6655155 (2)

1 6655155

  • 6655155 - SEAT
  • inlet valve

2 6655160

  • 6655160 - PLUG

3 6667421

  • 6667421 - BOLT

4 6652670

  • 6652670 - STUD 5

5 6652792

  • 6652792 - NUT

6 6EM80

  • 6EM80 - WASHER
  • SPRING

7 1EM80

  • 1EM80 - WASHER PLAIN
  • Was 2EM8

8 6686980

  • 6686980 - HEAD
  • cylinder - W/Ref. 10 - 14

9 6672144

  • 6672144 - GASKET
  • cylinder head

10 3974432

  • 3974432 - PLUG
  • sealing

11 3974433

  • 3974433 - PLUG
  • sealing

12 6598116

  • 6598116 - PLUG

13 6655154

  • 6655154 - GUIDE
  • VALVE
  • intake valve

14 6969990

  • 6969990 - GUIDE
  • exhaust valve - Was 6653803

15 6655158

  • 6655158 - BOLT

16 6655161

  • 6655161 - WASHER
  • W/rubber

17 6655156

  • 6655156 - SEAT VALVE EXHAUST
  • exhaust valve

18 3974882

  • 3974882 - HOOK

19 6674698

  • 6674698 - KIT
  • GASKET
  • upper - Was 6657401
