RING, PISTON 6672896
1 6672896
- 6672896 - RING
- PISTON
2 6666404
- 6666404 - RING
- SNAP
3 6666470
- 6666470 - PIN
4 6673152
- 6673152 - PISTON
- ENG
- W/Ref. 1-3
5 6673150
- 6673150 - CRANKSHAFT
6 6666456
- 6666456 - WASHER
- THRUST
7 6669397
- 6669397 - BEARING
- MAIN
- 2nd undersized - 2.7362 in. ( 69.50 mm)
8 6669395
- 6669395 - BEARING
- MAIN
- 2.7559" (70
- 00mm) - std
9 6669396
- 6669396 - BEARING
- MAIN
- 1st undersized - 2.7461 in. (69.75 mm)
10 6672894
- 6672894 - BEARING
- 2nd undersized - 2.145" (54
- 50mm) - Was 6666459
11 6672893
- 6672893 - BEARING
- 1st undersized - 2.155 in. (54
- 75 mm) - Was 6666458
12 6672889
- 6672889 - BEARING
- 2.165" (55
- 00mm) - std
13 6668943
- 6668943 - ROD
- CONNECTING
- connecting - W/Ref. 10-12
14 6668942
- 6668942 - ROD BOLT
15 6666442
- 6666442 - NUT
16 6666463
- 6666463 - BUSHING
17 6666471
- 6666471 - PULLEY
18 6666482
- 6666482 - FLANGE
19 6666444
- 6666444 - BOLT
20 6666446
- 6666446 - PULLEY
21 6666433
- 6666433 - BOLT
22 6688307
- 6688307 - COVER REAR
- rear - Was 6666491
23 6632823
- 6632823 - GASKET
- LIQUID
- liquid - use between Ref. 18 & block
24 6672890
- 6672890 - ADAPTER
