CONTROLLER, ACS 6680410
1 6680410
- 6680410 - CONTROLLER
- ACS
- plastic - W/ 3-connector plug - Was 6676337
2 6717393
- 6717393 - LEVER
- throttle
3 7101672
- 7101672 - ACTUATOR
- W/Ref. 4 (58K120 O-ring) - Use W/Ref. 19 (7101705 adapter)
4 58K120
- 58K120 - O-RING
- Use W/Ref. 3 (NLA/ 6678775 actuator & 7101672 actuator)
5 6686220
- 6686220 - O-RING
- Use W/Ref. 3 (NLA/ 7103129 actuator)
6 6733292
- 6733292 - HARNESS
- ACS
- Was 6726925
7 6676537
- 6676537 - SWITCH
8 6684912
- 6684912 - SENSOR
- FOOT RH
- - Was 6680420
9 6676029
- 6676029 - SOLENOID
- LOCK SPOOL
10 6684911
- 6684911 - SENSOR
- FOOT LH
- - Was 6680421
11 6676029
- 6676029 - SOLENOID
- LOCK SPOOL
12 6718706
- 6718706 - DECAL
- WARNING
- raising cab
13 6734646
- 6734646 - DECAL
- WARNING
- selectable joystick controls
14 6728539
- 6728539 - DECAL
- WARNING
15 6727926
- 6727926 - DECAL
- OPERATION
- hand & foot controls
16 6727926
- 6727926 - DECAL
- OPERATION
- hand & foot controls - Was 6727941
17 7126869
- 7126869 - BRACKET
- Was 6726573
18 6726681
- 6726681 - LINK
- AFC POD
19 95D5
- 95D5 - NUT
20 6727496
- 6727496 - PIN
21 17C616
- 17C616 - BOLT 5
22 6725128
- 6725128 - ADAPTER
- actuator - W/ O-ring groove - Use W/Ref. 3 (NLA/ 6678775 actuator)
23 7101705
- 7101705 - ADAPTER
- ACTUATOR
- W/O O-ring groove - Use W/Ref. 3 (NLA/ 7103129 actuator & 7101672 actuator)
24 30H62
- 30H62 - CLIP
25 35C514
- 35C514 - SCREW FLGD HEX CAP
26 6729467
- 6729467 - SPACER
- COLLAR
27 6714726
- 6714726 - PLUG
28 69G436
- 69G436 - BOLT
29 7108236
- 7108236 - PIN
- Was 6718506
30 25E24
- 25E24 - WASHER
- Was 25E-22
31 6654139
- 6654139 - MOULDING BULK/FT
- sold per foot
32 84G3710
- 84G3710 - SCREW
33 6680479
- 6680479 - SHIELD
- LH - Was 6727284
34 6680478
- 6680478 - SHIELD
- RH - Was 6727231
35 43C408
- 43C408 - BOLT
36 17C608
- 17C608 - BOLT
37 95D6
- 95D6 - NUT HEXAGON
