Bobcat
/
863.0
/
SEAL 6666490 (2)

SEAL 6666490 (2)

SEAL 6666490 (2)

1 6666490

  • 6666490 - SEAL
  • lip - rear main

2 6666412

  • 6666412 - BOLT

3 6688307

  • 6688307 - COVER REAR
  • rear - Use W/Ref. 39 - Was 6666491

4 6666402

  • 6666402 - BOLT

5 6666469

  • 6666469 - WASHER
  • THRUST
  • thrust

6 6666523

  • 6666523 - CAMSHAFT
  • short stroke - non-EPA

7 6673154

  • 6673154 - CAMSHAFT
  • short & long stroke - EPA

8 6673821

  • 6673821 - CAMSHAFT
  • long stroke - non-EPA

9 6666393

  • 6666393 - SEAL RING

10 1KM10

  • 1KM10 - PLUG

11 6666394

  • 6666394 - WASHER

12 6666399

  • 6666399 - PLUG
  • short stroke - non-EPA

13 6666421

  • 6666421 - PLUG

14 6666389

  • 6666389 - CIRCLIP

15 6666476

  • 6666476 - SCREW
  • limit

16 6666483

  • 6666483 - SPRING

17 6688255

  • 6688255 - SETTING SCREW
  • Was 6666489

18 6666410

  • 6666410 - O-RING

19 6666408

  • 6666408 - O-RING

20 6666480

  • 6666480 - STOP
  • adjusting

21 6666450

  • 6666450 - NUT

22 6666426

  • 6666426 - SEAL RING

23 6666390

  • 6666390 - NUT

24 6666488

  • 6666488 - SET SCREW

25 6672942

  • 6672942 - SET SCREW

26 6666406

  • 6666406 - STUD

27 6666475

  • 6666475 - CLAMP

28 16DM6

  • 16DM6 - NUT
  • Was 6513908

29 6666496

  • 6666496 - PIN
  • locating

30 6673163

  • 6673163 - ROD
  • short stroke - non-EPA - Was 6666503

31 6673163

  • 6673163 - ROD
  • short & long stroke - EPA & long stroke non-EPA

32 6666465

  • 6666465 - SPRING

33 6666761

  • 6666761 - CAP

34 6666701

  • 6666701 - CLAMP

35 6666707

  • 6666707 - BOLT

36 6666715

  • 6666715 - BOLT

37 6666711

  • 6666711 - BOLT

38 6666720

  • 6666720 - WASHER

39 6666725

  • 6666725 - PULLEY

40 6666690

  • 6666690 - PLUG

41 6632823

  • 6632823 - GASKET
  • LIQUID
  • liquid - between Ref. 3 & block also between Ref. 40 & block

42 6666748

  • 6666748 - COVER
  • FRONT
  • front

43 6670555

  • 6670555 - KIT
  • BELT TIMING
  • Ref. 32
  • 33 & 37

44 6673167

  • 6673167 - SPRING
  • short & long stroke - EPA & long stroke non-EPA

45 6673165

  • 6673165 - O-RING
  • short & long stroke - EPA & long stroke non-EPA

46 6673164

  • 6673164 - CAPSULE
  • short & long stroke - EPA & long stroke non-EPA

47 6673166

  • 6673166 - WASHER
  • short & long stroke - EPA & long stroke non-EPA

48 16DM6

  • 16DM6 - NUT
  • short & long stroke - EPA & long stroke non-EPA - Was 6513908
