UPPER PLATE
1 7290512
- 7290512 - UPPER PLATE
2 7290513
- 7290513 - RUBBER BOOT
3 7290514
- 7290514 - SCREW
4 7290515
- 7290515 - BASE CONNECTION PLATE
5 7290516
- 7290516 - PLATE
6 7290517
- 7290517 - ROD
7 7290518
- 7290518 - SCREW
8 7290519
- 7290519 - RUBBER WEDGE
9 7290520
- 7290520 - HEIGHT ADJ.SCREW ASSY.
10 7290521
- 7290521 - HEIGHT ADJ. LIMITER
11 7290522
- 7290522 - PIN
12 7290523
- 7290523 - OUTER SCISSOR
13 7290524
- 7290524 - SPRING TENSIONING PLASTICS
14 7290525
- 7290525 - BUSHING
15 7290526
- 7290526 - SCREW
16 7290527
- 7290527 - SCISSOR ASSY.
17 7290528
- 7290528 - SCREW
18 7290529
- 7290529 - SCREW
19 7290530
- 7290530 - SCHOCK ABSORBER
20 7290531
- 7290531 - PIN
21 7290532
- 7290532 - SEGMENT
22 7290533
- 7290533 - CLIPS
23 7290534
- 7290534 - BUSHING
24 7290535
- 7290535 - NUT
25 7290536
- 7290536 - ROLLER
26 7290537
- 7290537 - INNER SCISSOR
27 7290538
- 7290538 - INNER ROLLER
28 7290539
- 7290539 - INDICATOR TAPE
29 7290540
- 7290540 - OUTER COVER
30 7290541
- 7290541 - INDICATOR SPRING
31 7290542
- 7290542 - WEIGHT ADJ. TENSIONING P.
32 7290543
- 7290543 - WEIGHT ADJ. SPRING
33 7290544
- 7290544 - WEIGHT ADJ.SCREW
34 7290545
- 7290545 - BEARING
