(B110C) - BACKHOE LOADER - TIER 4A (3/12-)
/
HYD VALVE SECTION 84233259

HYD VALVE SECTION 84233259

HYD VALVE SECTION 84233259

1 84233259

  • 84233259 - HYD VALVE SECTION

2 85825473

  • 85825473 - SEAL KIT

3 84232114

  • 84232114 - VALVE

4 87719000

  • 87719000 - VALVE PRESSURE RELIE
  • 240Bar
  • 3480Psi

5 85820130

  • 85820130 - BOOT

6 85824279

  • 85824279 - KIT

7 85824278

  • 85824278 - KIT

8 84232126

  • 84232126 - VALVE
  • 310Bar
  • 4496Psi

9 87617657

  • 87617657 - O-RING KIT

10 85825248

  • 85825248 - SEAL KIT
