HYDRAULIC VALVE 84161432 (2)
1 84161432
- 84161432 - HYDRAULIC VALVE
2 NSS
- NSS - NOT SOLD SEPARAT
3 87455974
- 87455974 - O-RING
- 0.097" Thk x 0.755" ID
4 NSS
- NSS - NOT SOLD SEPARAT
5 NSS
- NSS - NOT SOLD SEPARAT
6 NSS
- NSS - NOT SOLD SEPARAT
7 85815667
- 85815667 - BY-PASS VALVE
8 NSS
- NSS - NOT SOLD SEPARAT
9 9968488
- 9968488 - SPRING
10 85815668
- 85815668 - O-RING
11 9968468
- 9968468 - SEALING RING
- 0.097" Thk x 0.755" ID
12 9968467
- 9968467 - BACK-UP RING
13 9968466
- 9968466 - SEALING RING
14 87541939
- 87541939 - GASKET KIT
15 87541940
- 87541940 - SEAL
16 87426716
- 87426716 - VALVE
- CHECK
17 87426238
- 87426238 - VALVE
- CHECK
18 87426227
- 87426227 - DETENT
19 87426233
- 87426233 - PLUG
- 7/8" Male
20 NSS
- NSS - NOT SOLD SEPARAT
21 87455549
- 87455549 - SEAL KIT
22 84180587
- 84180587 - VALVE
23 84180588
- 84180588 - VALVE
24 87455580
- 87455580 - O-RING KIT
25 81868381
- 81868381 - CHECK VALVE
- 1-1/16" - 12
26 87455550
- 87455550 - SERVICE KIT
27 87426717
- 87426717 - VALVE PRESSURE RELIE
28 NSS
- NSS - NOT SOLD SEPARAT
