PEDAL ASSEMBLY 6584857 (1)

PEDAL ASSEMBLY 6584857 (1)

PEDAL ASSEMBLY 6584857 (1)

1 6584857

  • 6584857 - PEDAL ASSEMBLY

2 6584861

  • 6584861 - SPOOL

3 25K30020

  • 25K30020 - O-RING 10

4 6584863

  • 6584863 - WASHER

5 7D8

  • 7D8 - NUT 5

6 6584862

  • 6584862 - SPACER

7 799119

  • 799119 - RING

8 35C412

  • 35C412 - SCREW FLGD HEX CAP
  • Was 17C000412B

9 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

10 7D6

  • 7D6 - NUT

11 17C620

  • 17C620 - BOLT

12 6505076

  • 6505076 - SPRING

13 6630167

  • 6630167 - STOP
  • rubber

14 61D4

  • 61D4 - NUT 5

15 17C528

  • 17C528 - BOLT

16 6519417

  • 6519417 - SPRING

17 7D5

  • 7D5 - NUT

18 6584854

  • 6584854 - BRACKET

19 17C540

  • 17C540 - BOLT

20 6584855

  • 6584855 - ANGLE

21 61D5

  • 61D5 - NUT HEX FINISHED GR5

22 73K114

  • 73K114 - RING

23 17C516

  • 17C516 - BOLT

24 6E4

  • 6E4 - WASHER 10

25 6530620

  • 6530620 - VALVE BLK

26 6530626

  • 6530626 - SPOOL

27 6647876

  • 6647876 - O-RING
  • Was 6646631

28 25E14

  • 25E14 - WASHER FLAT

29 24K3

  • 24K3 - PLUG

30 6584870

  • 6584870 - WASHER
