Bobcat
/
440
/
FLOAT KIT 6816719

FLOAT KIT 6816719

FLOAT KIT 6816719

1 6816719

  • 6816719 - FLOAT KIT
  • float option - Ref. 2-17 - Was 6597449

2 799119

  • 799119 - RING

3 6531270

  • 6531270 - SLEEVE
  • DETENT

4 6586918

  • 6586918 - SCREW
  • DETENT

5 6587575

  • 6587575 - ADAPTER
  • detent

6 6589226

  • 6589226 - COVER
  • END
  • 0.63" flange

7 6592098

  • 6592098 - WASHER

8 6592105

  • 6592105 - BALL 5
  • detent

9 6592107

  • 6592107 - SPRING
  • DETENT 5
  • detent

10 6596807

  • 6596807 - PLUG
  • plastic - 0.46" long

11 6646372

  • 6646372 - SEAL
  • QUAD RING
  • quad ring seal

12 6660644

  • 6660644 - CAP

13 6665089

  • 6665089 - SEAL 5
  • lip seal - Was 6659554

14 6683274

  • 6683274 - SEAL
  • SPOOL 10
  • - spool - Was 6665846

15 29G416

  • 29G416 - BOLT

16 54K20002

  • 54K20002 - O'RING 10

17 6724789

  • 6724789 - INSTRUCTIONS
