HARNESS 6705136 (2)

HARNESS 6705136 (2)

HARNESS 6705136 (2)

1 6705136

  • 6705136 - HARNESS

2 35C412

  • 35C412 - SCREW FLGD HEX CAP

3 83D4

  • 83D4 - LKNUT HEX FLG GR8

4 30H54

  • 30H54 - CLIP

5 30H54

  • 30H54 - CLIP

6 6665606

  • 6665606 - SWITCH
  • IGN

7 6512808

  • 6512808 - SWITCH-LT

8 6702608

  • 6702608 - PANEL
  • INSTRUMENT
  • L.H.

9 6702660

  • 6702660 - PANEL
  • INSTRUMENT
  • R.H.

10 6667903

  • 6667903 - SWITCH
  • AUX
  • aux. controls - Was 6700603

11 6599781

  • 6599781 - KNOB
  • light switch

12 6660955

  • 6660955 - PLUG

13 6649331

  • 6649331 - SOCKETLIT
  • light - W/ 6" leads

14 17E8

  • 17E8 - WASHER

15 6660594

  • 6660594 - BUTTON
  • on/off

16 7131641

  • 7131641 - KIT
  • DISPLAY LCD
  • LCD monitor - screw mounted - includes screws
  • display & instructions

17 6691063

  • 6691063 - SCREW

18 6904890

  • 6904890 - INSTRUCTIONS

19 6578780

  • 6578780 - CROSSMEMBER

20 6709028

  • 6709028 - PLATE 10
  • ignition key - W/Ref. 5 (6665606 Switch) - Was 6708701

21 10C412

  • 10C412 - BOLT

22 6651975

  • 6651975 - SWITCH
  • RELAY MAGNETIC
  • relay

23 6704892

  • 6704892 - RIVET

24 6702642

  • 6702642 - SCREW WSHRD PLASTITE

25 61D4

  • 61D4 - NUT 5

26 7239135

  • 7239135 - SHIELD
  • snap in place - Was 6700487

27 12D8

  • 12D8 - NUT HEX MACH SCREW

28 6578357

  • 6578357 - BULB 10

29 6630138

  • 6630138 - SEAL
  • BULK
  • bulk - sold per foot

30 7269395

  • 7269395 - CAP
  • Was 6651703

31 6669225

  • 6669225 - SCREW
  • Was 58G000408B

32 6512809

  • 6512809 - KEYSET 10
  • ignition - for Ref. 5 (NLA/6519592 Switch)

33 6693241

  • 6693241 - KEY (2)
  • ignition - single key W/O ring

34 6702678

  • 6702678 - DECAL
  • service codes

35 6724282

  • 6724282 - KIT
  • SWITCH IGN
  • Ref. 5
  • 17 & 30

36 6598721

  • 6598721 - NUT
  • W/Ref. 5 (NLA/6519592 Switch)

37 6674202

  • 6674202 - NUT
  • W/Ref. 5 (6665606 Switch)
