RETAINER 6589564 (4)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 7202038
- 7202038 - BUSHING
- ALIGNMENT
- Also Order 82K019 alignment O-ring - Was 6805102
4 99K6
- 99K6 - O-RING
5 6814511
- 6814511 - SPOOL
- LIFT
- Was 6811411
6 6815152
- 6815152 - SPOOL
- TILT
- Was 6811412
7 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
8 6592115
- 6592115 - SEAT
- load check
9 6592117
- 6592117 - SPRING
- LOAD CHECK
10 79K8
- 79K8 - O RING 10
11 6592116
- 6592116 - NUT
- load check
12 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 16-18
13 79K10
- 79K10 - O RING 10
14 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
15 6677106
- 6677106 - O-RING
16 6678574
- 6678574 - VALVE
- RELIEF
- port relief - W/Ref. 16-18 - 3500 PSI - Was 6678574
17 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
18 58K017
- 58K017 - O-RING 10
19 6665569
- 6665569 - RING
- BACK-UP
- back-up
20 25K20016
- 25K20016 - O RING 10
21 6665570
- 6665570 - CLYD RING
- glide
22 6595663
- 6595663 - BUSHING
23 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
24 6587580
- 6587580 - SPRING
25 6592100
- 6592100 - COLLAR
26 6596807
- 6596807 - PLUG
- plastic - 0.46" long
27 6586918
- 6586918 - SCREW
- DETENT
28 6587575
- 6587575 - ADAPTER
29 6592107
- 6592107 - SPRING
- DETENT 5
30 6592105
- 6592105 - BALL 5
31 6531270
- 6531270 - SLEEVE
- DETENT
32 6592098
- 6592098 - WASHER
33 799119
- 799119 - RING
34 6589226
- 6589226 - COVER
- END
- 0.63" flange
35 6660644
- 6660644 - CAP
36 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
37 30G416
- 30G416 - BOLT
38 6592109
- 6592109 - ADAPTER
39 6683274
- 6683274 - SEAL
- SPOOL 10
- spool - Was 6665846
40 6805651
- 6805651 - AUX BLOCK
- aux.
41 58K124
- 58K124 - O RING 10
42 6596332
- 6596332 - SPRING
43 7108780
- 7108780 - SLEEVE
- Was 6595951
44 6592720
- 6592720 - PLUG
- W/Ref. 16-18
45 1K127
- 1K127 - O-RING 10
- Was 93K127
46 6817553
- 6817553 - CROSS
- W/Ref. 6 - Was 6805241
47 55K204
- 55K204 - O RING 10
48 29G444
- 29G444 - BOLT
49 29G416
- 29G416 - BOLT
- 1" long
50 6662848
- 6662848 - CAP
51 6805696
- 6805696 - TEE
- W/Ref. 6 - tapered boss face
52 97K6
- 97K6 - O-RING
- flare end
53 6806496
- 6806496 - TUBELINE
54 6588781
- 6588781 - END CAP
55 6676249
- 6676249 - STEM
- VALVE SOLENOID
56 6679961
- 6679961 - NUT
- coil
57 6586459
- 6586459 - SEAL KIT
58 6717706
- 6717706 - COIL
- 10 VOLT
- pwm - 10 volt - w/nut
59 6676566
- 6676566 - NUT
60 6678552
- 6678552 - RELIEF VLV ANTI-CAV
- port relief & anti-cav. - W/Ref. 16 & 18 - 3500 PSI - use in tilt cylinder base end port - Was 6671632
61 6673904
- 6673904 - SEAL KIT
- W/Ref. 16
- 67
- 68
62 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 4
- 13
- 16
- 18
- 21-24
- 42
- 44
- 50-52 & 63 - also Order 6816252 seal kit - Was 6809448
63 6661328
- 6661328 - SEAL KIT
- main relief - Ref. 21-24
64 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 16-18
65 6816252
- 6816252 - SEAL KIT
- two spool - Ref. 4
- 29
- 42
- 48
- 51 & 64 - Was 6806941
66 6595131
- 6595131 - SPRING
- .72'' OD
67 55K212
- 55K212 - O RING 10
68 54K20002
- 54K20002 - O'RING 10
69 6812171
- 6812171 - PLUG
- W/Ref. 66 - Was 90KV00005B
70 95K6
- 95K6 - O'RING
71 6812031
- 6812031 - SPOOL LOCK BLOCK
- lift and tilt lock - Was 6805657
72 90K8
- 90K8 - PLUG
- W/Ref. 71 - Was 90KV00008B
73 95K12
- 95K12 - O-RING
74 6806561
- 6806561 - PLUG W/SEALS
- aux lock - W/Ref. 73 & 74
75 79K7
- 79K7 - O RING 10
76 25K20012
- 25K20012 - O RING 10
- Was 58K000012B
77 6676029
- 6676029 - SOLENOID
- LOCK SPOOL
- 127 mm (5") wire - W/Ref. 13 - 3-pin connector - Order for production valve
78 6734058
- 6734058 - TUBELINE
79 6681933
- 6681933 - CHECK VALVE
- 3000 PSI - W/screen - W/Ref. 78
80 79K6
- 79K6 - O RING 10
81 6812171
- 6812171 - PLUG
- W/Ref. 66
