RETAINER 6589564 (1)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 7202038
- 7202038 - BUSHING
- ALIGNMENT
- Also Order 82K019 alignment O-ring - Was 6805102
4 99K6
- 99K6 - O-RING
5 6814511
- 6814511 - SPOOL
- LIFT
6 6815152
- 6815152 - SPOOL
- TILT
- Was 6811412
7 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
8 6592115
- 6592115 - SEAT
- load check
9 6592117
- 6592117 - SPRING
- LOAD CHECK
10 79K8
- 79K8 - O RING 10
11 6592116
- 6592116 - NUT
- load check
12 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 16-18
13 79K10
- 79K10 - O RING 10
14 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
15 58K014
- 58K014 - O-RING 10
- back-up washer required
16 6677106
- 6677106 - O-RING
- back-up washer not required
17 6678574
- 6678574 - VALVE
- RELIEF
- port relief - W/Ref. 16-18 - Was 6673184
18 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
19 58K017
- 58K017 - O-RING 10
20 6665569
- 6665569 - RING
- BACK-UP
- back-up
21 25K20016
- 25K20016 - O RING 10
22 6665570
- 6665570 - CLYD RING
- glide
23 6595663
- 6595663 - BUSHING
24 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
25 6587580
- 6587580 - SPRING
26 6592100
- 6592100 - COLLAR
27 6596807
- 6596807 - PLUG
- plastic - 0.46" long
28 6586918
- 6586918 - SCREW
- DETENT
29 6587575
- 6587575 - ADAPTER
30 6592107
- 6592107 - SPRING
- DETENT 5
31 6592105
- 6592105 - BALL 5
32 6531270
- 6531270 - SLEEVE
- DETENT
33 6592098
- 6592098 - WASHER
34 799119
- 799119 - RING
35 6589226
- 6589226 - COVER
- END
- 0.63" flange
36 6660644
- 6660644 - CAP
37 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
38 30G416
- 30G416 - BOLT
39 6592109
- 6592109 - ADAPTER
40 6683274
- 6683274 - SEAL
- SPOOL 10
- spool - Was 6665846
41 6805651
- 6805651 - AUX BLOCK
- aux
42 58K124
- 58K124 - O RING 10
43 6596332
- 6596332 - SPRING
44 7108780
- 7108780 - SLEEVE
- Was 6595951
45 6592720
- 6592720 - PLUG
- W/Ref. 16-18
46 1K127
- 1K127 - O-RING 10
- Was 93K127
47 6805243
- 6805243 - FITTING ELBOW
- W/ 2 male JIC ends - W/Ref. 6 - For 6806150 valve
48 6727931
- 6727931 - TEE
- W/ 3 male JIC ends - W/Ref. 6 - for 6809267 & 6810244 valves
49 55K204
- 55K204 - O RING 10
50 29G444
- 29G444 - BOLT
51 29G416
- 29G416 - BOLT
- 1" long
52 6662848
- 6662848 - CAP
53 97K6
- 97K6 - O-RING
- flared end
54 6805696
- 6805696 - TEE
- W/Ref. 6 - tapered boss face
55 6806496
- 6806496 - TUBELINE
56 6588781
- 6588781 - END CAP
57 6676249
- 6676249 - STEM
- VALVE SOLENOID
- Was 6666616
58 6679961
- 6679961 - NUT
- Coil
59 6586459
- 6586459 - SEAL KIT
60 6717706
- 6717706 - COIL
- 10 VOLT
- W/ nut - 10 volt - pwm
61 6676566
- 6676566 - NUT
62 6678552
- 6678552 - RELIEF VLV ANTI-CAV
- Port Relief & Anti-cav. - W/Ref. 16 - 3500 PSI - Use In Tilt Cylinder Base End Port - Was 6671632
63 6673904
- 6673904 - SEAL KIT
- W/Ref. 16
- 67 & 68
64 6816252
- 6816252 - SEAL KIT
- two spool - Ref. 4
- 26
- 26
- 42
- 48
- 51 & 64 - Was 6806941
65 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 4
- 13
- 16-18
- 21-24
- 42
- 44
- 50- 52 & 63 - also Order 6816252 seal kit - Was 6809448
66 6809425
- 6809425 - SEAL KIT
- upper deck - Ref. 13 & 16-18 - Was 6586461
67 6661328
- 6661328 - SEAL KIT
- main relief - Ref. 21-24
68 6595131
- 6595131 - SPRING
- .72'' OD - Red
69 55K212
- 55K212 - O RING 10
70 54K20002
- 54K20002 - O'RING 10
71 6596569
- 6596569 - SEAT
- load check
72 95K6
- 95K6 - O'RING
73 6812031
- 6812031 - SPOOL LOCK BLOCK
- lift and tilt lock - Was 6805657
74 90K8
- 90K8 - PLUG
- W/Ref. 71 - Was 90KV00008B
75 95K12
- 95K12 - O-RING
76 6806561
- 6806561 - PLUG W/SEALS
- W/Ref. 73 & 74
77 79K7
- 79K7 - O RING 10
78 25K20012
- 25K20012 - O RING 10
- Was 58K-12
79 6677383
- 6677383 - SOLENOID
- LOCK SPOOL
- 2-pin connector - 127 mm (5") wire - W/Ref. 13 - Order for valve 7222854
80 6668791
- 6668791 - ORIFICE
- 0.185
81 6812171
- 6812171 - PLUG
- W/Ref. 66 - Was 90KV00005B
