RETAINER 6589564 (5)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 6589565
- 6589565 - SEAL
4 7108251
- 7108251 - SPOOL
- LIFT
5 7108242
- 7108242 - SPOOL
- TILT
6 7300937
- 7300937 - SPOOL AUX
- auxiliary - Was 6588074
7 6592115
- 6592115 - SEAT
- load check
8 6592117
- 6592117 - SPRING
- LOAD CHECK
9 79K8
- 79K8 - O RING 10
10 6592116
- 6592116 - NUT
- load check - W/Ref. 12
11 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
12 58K017
- 58K017 - O-RING 10
13 6665569
- 6665569 - RING
- BACK-UP
- back-up
14 25K20016
- 25K20016 - O RING 10
15 6665570
- 6665570 - CLYD RING
- glide
16 6595663
- 6595663 - BUSHING
17 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
18 6587580
- 6587580 - SPRING
19 6592100
- 6592100 - COLLAR
20 6801167
- 6801167 - SPOOLPLUG
- plastic - 0.69" long
21 24K8
- 24K8 - PLUG
- W/Ref. 25 - socket head
22 95K12
- 95K12 - O-RING
23 6800124
- 6800124 - RESTRICTOR
24 55K212
- 55K212 - O RING 10
25 55K204
- 55K204 - O RING 10
26 54K20002
- 54K20002 - O'RING 10
27 6803092
- 6803092 - BONNET
- .625 flange
28 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
29 30G416
- 30G416 - BOLT
30 6592109
- 6592109 - ADAPTER
31 6683274
- 6683274 - SEAL
- SPOOL 10
- - lip
32 6588781
- 6588781 - END CAP
- .87" thick
33 58K124
- 58K124 - O RING 10
34 7108780
- 7108780 - SLEEVE
35 6596332
- 6596332 - SPRING
36 6595131
- 6595131 - SPRING
- .72'' OD
37 6592720
- 6592720 - PLUG
- W/Ref. 41-43
38 79K10
- 79K10 - O RING 10
39 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
40 6677106
- 6677106 - O-RING
41 1K127
- 1K127 - O-RING 10
- Was 93K127
42 29G412
- 29G412 - BOLT
43 29G416
- 29G416 - BOLT
- 1" long
44 6662848
- 6662848 - CAP
45 6806561
- 6806561 - PLUG W/SEALS
- W/Ref. 49 & 50
46 79K7
- 79K7 - O RING 10
47 25K20012
- 25K20012 - O RING 10
48 6805651
- 6805651 - AUX BLOCK
- aux
49 6812171
- 6812171 - PLUG
- W/Ref. 53
50 95K6
- 95K6 - O'RING
51 7123961
- 7123961 - SEAL KIT
- COMPLETE
- Includes all seal kits
52 6673904
- 6673904 - SEAL KIT
- port relief - W/Ref. 41-43
53 7123963
- 7123963 - SEAL KIT
- EXTERNAL FITTING
- 3 spool - W/Ref. 4
- 23
- 29
- 34
- 36
- & 44
54 6632279
- 6632279 - KIT
- SEAL
- main relief - W/Ref. 15-18
55 6669732
- 6669732 - KIT
- SEAL
- solenoid valve
56 6690431
- 6690431 - KIT
- SEAL
- Was 6669734
57 7123962
- 7123962 - SEAL KIT
- 3 SPOOL
- external fitting - W/Ref. 12
- 25
- 27
- 28
- 49
- 50
- & 53
