SPOOL 7006878

SPOOL 7006878

SPOOL 7006878

1 7006878

  • 7006878 - SPOOL

2 7284551

  • 7284551 - O-RING
  • Was 7007909

3 7004646

  • 7004646 - O-RING

4 7006879

  • 7006879 - SPRING

5 7007738

  • 7007738 - BOLT SOCKET M8X25

6 7004443

  • 7004443 - FILTER

7 7006957

  • 7006957 - SOLENOID B
  • Was 7006958

8 7006958

  • 7006958 - SOLENOID A
  • Was 7006957

9 7004283

  • 7004283 - PLUG

10 7004287

  • 7004287 - PLUG

11 7007903

  • 7007903 - O-RING

12 7004194

  • 7004194 - SPRING

13 7007870

  • 7007870 - BALL STEEL
