HARNESS, MAIN 7008223

HARNESS, MAIN 7008223

HARNESS, MAIN 7008223

1 7008223

  • 7008223 - HARNESS
  • MAIN
  • W/Ref. 2-3

2 7019189

  • 7019189 - HARNESS MAIN
  • W/Ref. 2-3

3 7004913

  • 7004913 - RESITOR DIODE

4 7005030

  • 7005030 - RESISTOR DIODE ASSY 3A

5 7004615

  • 7004615 - CAP BATT TML +
  • positive

6 7004616

  • 7004616 - CAP BATT TML -
  • negative

7 7004920

  • 7004920 - CABLE BATTERY-EARTH

8 7004923

  • 7004923 - CABLE BATT-BATT RY

9 7004918

  • 7004918 - CABLE BATT RY-STARTER

10 7005037

  • 7005037 - CABLE E/G EARTH

11 7007623

  • 7007623 - BOLT

12 7007818

  • 7007818 - WASHER PLAIN M10

13 7007835

  • 7007835 - WASHER SPRING

14 7004896

  • 7004896 - LINK FUSIBLE

15 7004825

  • 7004825 - BRACKET HOUSING

16 7004826

  • 7004826 - BRACKET HOUSING

17 7004826

  • 7004826 - BRACKET HOUSING

18 7003871

  • 7003871 - BOLT STUD

19 7007835

  • 7007835 - WASHER SPRING

20 7003870

  • 7003870 - BOLT STUD

21 7276756

  • 7276756 - WASHER
  • Was 7007834

22 7003902

  • 7003902 - CLIP

23 7003905

  • 7003905 - CLIP
  • Was 7003896

24 7003904

  • 7003904 - CLIP
  • Was 7003895

25 7003903

  • 7003903 - CLIP
  • Was 7003894

26 7004561

  • 7004561 - NUT

27 7005629

  • 7005629 - BOLT

28 7005629

  • 7005629 - BOLT

29 7005009

  • 7005009 - LINK FUSIBLE

30 7003897

  • 7003897 - CLIP

31 7007833

  • 7007833 - WASHER
  • SPRING

32 7007602

  • 7007602 - BOLT

33 7007796

  • 7007796 - NUT

34 7007816

  • 7007816 - WASHER

35 7276756

  • 7276756 - WASHER
  • Was 7007834

36 7003905

  • 7003905 - CLIP

37 7004824

  • 7004824 - BRACKET HOUSING

38 7003893

  • 7003893 - CLIP

39 7004917

  • 7004917 - TERMINAL BATTERY +
  • positive

40 7008150

  • 7008150 - TERMINAL
  • BATTERY(-)
  • negative
