Bobcat
/
E60
/
TEE 7004742

TEE 7004742

TEE 7004742

1 7004742

  • 7004742 - TEE

2 7005560

  • 7005560 - ELBOW
  • Was 7004687

3 7004725

  • 7004725 - ELBOW

4 7005547

  • 7005547 - ADAPTER

5 7003877

  • 7003877 - NUT

6 7005559

  • 7005559 - ELBOW

7 7021859

  • 7021859 - FITTING
  • HYD ELBOW

8 7276399

  • 7276399 - CLAMP

9 7005940

  • 7005940 - VALVE BYPASS

10 7003951

  • 7003951 - ADAPTER

11 7006424

  • 7006424 - TUBELINE SUCTION

12 7004634

  • 7004634 - O-RING

13 7007845

  • 7007845 - WASHER SPRING

14 7007762

  • 7007762 - BOLT SOCKET M12X1.75X40

15 7007920

  • 7007920 - O-RING

16 7013250

  • 7013250 - HOSE

17 7005191

  • 7005191 - HOSE

18 7005178

  • 7005178 - HOSE

19 7022861

  • 7022861 - HOSE HYDRAULIC ASSY

20 7021847

  • 7021847 - HOSE HYDRAULIC ASSY

21 7008164

  • 7008164 - HOSE

22 7022862

  • 7022862 - HOSE HYDRAULIC ASSY

23 7003901

  • 7003901 - CLIP

24 7005629

  • 7005629 - BOLT

25 7005629

  • 7005629 - BOLT

26 7021856

  • 7021856 - HOSE HYDRAULIC ASSY

27 7003897

  • 7003897 - CLIP

28 7021804

  • 7021804 - BRACKET
  • MOUNTING
